*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 126.62141 Part Description
Manufacturer
Product Description
Centric Premium OE Style Slotted Brake Rotor
Application Summary
Chevrolet Corvette 2019-2014
Features & Benefits
- Premium e-coated rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
Centric OE Brake Rotor; CentricParts Rotor; Centric Parts Rotor; CentricParts Rotor
CENTRIC 126.62141 Specifications
Product Attributes
| Discard Thickness | 24.000 MM |
| Nominal Thickness | 26.000 MM |
| Hat Finish | Coated |
| Overall Height | 48.100 MM |
| Outside Diameter | 13.346 IN |
| ABS Tone Ring Included | No |
| Surface Type | Slotted |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 200.900 MM |
| Bearings Included | No |
| Center Hole Diameter | 70.800 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.000 MM |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] In | 5.980 |
| Hat Id [cntrc] Mm | 151.900 |
| Max Pb Drum Dia [cntrc] In | 7.933 |
| Max Pb Drum Dia [cntrc] Mm | 201.500 |
| Misc Holes [cntrc] | 1 |
| Notes [cntrc] | Can use 126.62139 in place of original rotor |
| OEM Vane Count [cntrc] | 186 |
| Vane Style [cntrc] | Pillar |
| Weight [cntrc] Kgs | 9.060 |
| Weight [cntrc] Lbs | 19.950 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 0.945 IN |
| Nominal Thickness | 1.024 IN |
| Overall Height | 1.894 IN |
| Outside Diameter | 339.000 MM |
| Nominal Drum Diameter | 7.909 IN |
| Center Hole Diameter | 2.787 IN |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Diameter | 0.591 IN |
Additional Information
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| UPC | 00889590204025 |
CENTRIC 126.62141 Cross References
CENTRIC 126.62141 Fits Vehicles
- Chevrolet Corvette (2014-2019)
