(888) 312-8812 Login SignupRAYBESTOS 581613FZN Raybestos Element3 Coated Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 581613FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2019-2014 Chevrolet Corvette Rear
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 581613FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.783 IN |
| Center Hole Diameter | 70.7 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.945 IN |
| Discard Thickness | 24 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.425 IN |
| Inside Diameter | 239.4 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
| Mounting Bolt Hole Diameter | 15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26 MM |
| Outside Diameter | 13.343 IN |
| Outside Diameter | 338.9 MM |
| Overall Height | 1.909 IN |
| Overall Height | 48.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213236453 |
RAYBESTOS 581613FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH508483 |
| AutoZone | 72053DG, 72053DL |
| BRAKEBEST | 521619RGS, 581613, 581613FZN, 581613R |
| CENTRIC | 120.62141, 121.62141, 126.62141, 126.62141SL, 126.62141SR, 127.62141L, 127.62141R, 226.62141 |
| Centric Parts | 120.62141, 121.62141, 126.62141SL, 126.62141SR, 127.62141L, 127.62141R, 226.62141, 126.62141 |
| Dura Corp | BR901668 |
| DuraGo | BR901668 |
| Dynamic Friction Company | 604-47047, 614-47047 |
| GM | 20981820, 23213199, 23322784 |
| General Motors | 20981820, 23213199, 23322784 |
| NEWTEK AUTOMOTIVE | R1668 |
| Newtek Automotive USA | R1668 |
| PROMAX | 14-650001 |
| Qualis | 41285, 61316, 61332 |
| WORLDPAC | 1427-566216 |
RAYBESTOS 581613FZN Fits Vehicles
- Chevrolet Corvette (2014-2019)
RAYBESTOS 581613FZN Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 581613FZN Questions & Answers
No questions yet
Be the first to ask a question about this product!
