(888) 312-8812 Login SignupNGK SPARK PLUGS 3992 NGK Racing Spark Plug
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS 3992 Part Description
Manufacturer
Product Description
NGK Racing Spark Plug
Features & Benefits
- DESIGNED FOR RACING: Conventional nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Racing use only
- RECOMMENDED USAGE: Racing use only, featuring special configurations and designs to ensure durability and ignitability
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
SPARK PLUG
NGK SPARK PLUGS 3992 Specifications
Product Attributes
| Stock Number | 3992 |
| Part Number | BR8EG SOLID |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .024 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16 IN |
| Insulator Height | 53.8 MM |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 14.00 MM |
| Short Style Spark Plug | No |
| Service Number | BR8EG SOLID |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Hex Size | 13/16" |
| Insulator Height | 2.12 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.04 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Thread Size | M14 - 1.25 |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.6 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 1.0 MM |
Additional Information
| Warranty Time UOM | MO |
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295139929 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS 3992 Cross References
| Brand | Part Number |
|---|---|
| E3 SPARK PLUGS | E331 |
| NGK | 3992 |
| NGK SPARK PLUGS | BR8EG SOLID, 3992 |
NGK SPARK PLUGS 3992 Fits Vehicles
- KTM 200 XC-W (2006-2016)
- KTM 200 XC (2006-2009)
- Gas Gas Wild HP 300 (2003-2005)
- Suzuki RM250 (2001-2002)
- KTM 200 MXC (1998-2003)
- KTM 200 EXC (1998-2005)
- Kawasaki KX500 (1998-2004)
- Yamaha YZ250 (1996-2002)
NGK SPARK PLUGS 3992 Customer Reviews
No reviews yet
Be the first to review this product!
NGK SPARK PLUGS 3992 Manufacturer Information
Headquartered in Wixom, Michigan, NGK® is a global leader in the design and manufacture of spark plugs for virtually every automotive and commercial vehicle application. It has grown immensely since its inception in 1936 with the expansion of its ignition product line and the introduction of its technical sensor and vehicle electronics line. NGK partners with OEMs and uses only the latest cutting tools to ensure each NGK product meets OE specifications for exact fit, form, and function. With world-class quality and engineering, NGK’s expertise goes beyond manufacturing the most reliable spark plugs for the automotive industry but also providing the best customer service possible.
NGK SPARK PLUGS 3992 Questions & Answers
No questions yet
Be the first to ask a question about this product!
