NGK SPARK PLUGS BR8EG SOLID Part Description
Manufacturer
Product Description
NGK Racing Spark Plug
Features & Benefits
- DESIGNED FOR RACING: Conventional nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Racing use only, featuring special configurations and designs to ensure durability and ignitability
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BR8EG SOLID Specifications
Product Attributes
| Stock Number | 3992 |
| Part Number | BR8EG SOLID |
| Short Style Spark Plug | No |
| Service Number | BR8EG SOLID |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .024 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.12 IN |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.04 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.6 MM |
| Insulator Height | 53.8 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 1.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295139929 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BR8EG SOLID Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | 4063 |
| N/A | BR8EG SOLID |
| NGK | 3992 |
NGK SPARK PLUGS BR8EG SOLID Fits Vehicles
- KTM 200 XC-W (2006-2016)
- KTM 200 XC (2006-2009)
- Gas Gas Wild HP 300 (2003-2005)
- Suzuki RM250 (2001-2002)
- KTM 200 MXC (1998-2003)
- KTM 200 EXC (1998-2005)
- Kawasaki KX500 (1998-2004)
- Yamaha YZ250 (1996-2002)
