(888) 312-8812 Login SignupCENTRIC 125.35108 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 4 more
MSRP: $148.92
$12549
Save $23.43
Limited availability at this price!
In Stock
Get it by Thursday, Mar 12
CENTRIC 125.35108 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.35108 Specifications
Product Attributes
| Weight [cntrc] Kgs | 10.200 |
| Hat Id [cntrc] Mm | 170.000 |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 22.450 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] In | 6.693 |
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Pillar |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25.000 MM |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Hat Finish | Painted |
| Overall Height | 93.000 MM |
| Overall Height | 3.661 IN |
| Outside Diameter | 303.000 MM |
| Outside Diameter | 11.929 IN |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.724 IN |
| Center Hole Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 145.200 MM |
| Mounting Bolt Hole Circle Diameter | 5.717 IN |
| Mounting Bolt Hole Diameter | 15.000 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890730156 |
CENTRIC 125.35108 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD126505, 428202, E125-40-113, E130-40-113, R4414737, 43165, YH200457, 53047G, 2E0615601, 9074230100, 9064230112, 68013765AA, 780612P, 850061, DF4919S, 90063134, E12540113, E13040113 |
| RAYBESTOS | 780612, 780612R |
| Raybestos Brakes | 780612R, 780612 |
CENTRIC 125.35108 Fits Vehicles
- Freightliner Sprinter 3500 (2007-2020)
- Freightliner Sprinter 2500 (2019-2020)
- Mercedes-Benz Sprinter 2500 (2019-2020)
- Mercedes-Benz Sprinter 3500XD (2018-2023)
- Dodge Sprinter 3500 (2007-2009)
- Volkswagen Crafter Van (2008-2017)
- Mercedes-Benz Sprinter 4500 (2019-2023)
- Mercedes-Benz Sprinter 3500 (2010-2023)
