(888) 312-8812 Login SignupRAYBESTOS 780612R Raybestos R-Line Brake Rotor
$21699
Limited availability at this price!
In Stock
Get it by Thursday, Mar 12
RAYBESTOS 780612R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2023-2010 Mercedes-Benz Sprinter 3500 Rear, 2018-2007 Freightliner Sprinter 3500 Rear, 2009-2007 Dodge Sprinter 3500 Rear, 2020-2019 Freightliner Sprinter 2500 Rear, 2023-2018 Mercedes-Benz Sprinter 3500XD Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 780612R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.724 IN |
| Center Hole Diameter | 120 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.98 IN |
| Discard Thickness | 24.9 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.7 IN |
| Mounting Bolt Hole Circle Diameter | 144.8 MM |
| Mounting Bolt Hole Diameter | 5.7 IN |
| Mounting Bolt Hole Diameter | 144.8 MM |
| Nominal Thickness | 1.1 IN |
| Nominal Thickness | 27.95 MM |
| Outside Diameter | 11.929 IN |
| Outside Diameter | 303 MM |
| Overall Height | 3.661 IN |
| Overall Height | 93 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352788806 |
RAYBESTOS 780612R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH200457, YH200457C, YH200457P |
| AUTOZONE | 43165, 43165DG |
| BRAKEBEST | 16011500, 780612, 780612R, 780612RGS |
| Brembo | 09.9510.14 |
| CENTRIC | 120.35108, 121.35108, 125.35107CRY, 125.35108, 125.35108CRY, 126.35108SL, 126.35108SR, 127.35108L, 127.35108R, 320.35108, 320.35108H |
| CHRYSLER | 68013765AA |
| Centric Parts | 120.35108, 121.35108, 125.35107CRY, 125.35108, 125.35108CRY, 126.35108SL, 126.35108SR, 127.35108L, 127.35108R, 320.35108, 320.35108H |
| DURA CORP | BR53047, BR900310 |
| DuraGo | 60368, 900310, BR60368, BR900310 |
| MAGMA PRODUCTS | PMR385103 |
| MERCEDES-BENZ | 9064230112, 9074230100, 907423010007, A9064230112, A907423010007 |
| N/A | 120.35107 |
| NAPA BRAKES | SDK6474 |
| NEWTEK AUTOMOTIVE | 53047 |
| Newtek Automotive USA | 53047 |
| PAGID | 355123182 |
| PAGID Racing | 355123182 |
| PROMAX | 14-53047 |
| Qualis | 43165 |
| TRW | 4919 |
| UAP | 780612 |
| Ultra Brake | ME-206 |
| VAICO | V1080092 |
| WAGNER BRAKE | BD126505 |
| WINHERE | 6620454 |
| WORLDPAC | 1427-732796 |
| Wagner Brake | BD126505E |
RAYBESTOS 780612R Fits Vehicles
- Freightliner Sprinter 2500 (2019-2020)
- Freightliner Sprinter 3500 (2007-2020)
- Mercedes-Benz Sprinter 2500 (2019-2020)
- Mercedes-Benz Sprinter 3500XD (2018-2024)
- Mercedes-Benz Sprinter 4500 (2019-2023)
- Mercedes-Benz Sprinter 3500 (2010-2024)
- Volkswagen Crafter Van (2008-2017)
- Dodge Sprinter 3500 (2007-2009)
