(888) 312-8812 Login SignupCENTRIC 320.35108H Centric GCX Rotor with Full Coating and High Carbon Content
Tap to view 4 more
$17149
Limited availability at this price!
In Stock
Get it by Thursday, Mar 12
CENTRIC 320.35108H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.35108H Specifications
Product Attributes
| Weight [cntrc] Kgs | 10.200 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 170.000 |
| Weight [cntrc] Lbs | 22.450 |
| Vane Style [cntrc] | Pillar |
| Disc Mounting [cntrc] | Behind the Hub |
| Hat Id [cntrc] In | 6.693 |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25.000 MM |
| Nominal Thickness | 28.000 MM |
| Nominal Thickness | 1.102 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 93.000 MM |
| Overall Height | 3.661 IN |
| Outside Diameter | 11.929 IN |
| Outside Diameter | 303.000 MM |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.724 IN |
| Center Hole Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 145.200 MM |
| Mounting Bolt Hole Circle Diameter | 5.717 IN |
| Mounting Bolt Hole Diameter | 15.000 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00889590388176 |
CENTRIC 320.35108H Cross References
| Brand | Part Number |
|---|---|
| BREMBO | 08.D045.11 |
| RAYBESTOS | 780612, 780612R |
| Raybestos Brakes | 780612R, 780612 |
CENTRIC 320.35108H Fits Vehicles
- Freightliner Sprinter 2500 (2019-2020)
- Freightliner Sprinter 3500 (2007-2020)
- Mercedes-Benz Sprinter 3500XD (2018-2023)
- Mercedes-Benz Sprinter 4500 (2019-2023)
- Volkswagen Crafter Van (2008-2017)
- Dodge Sprinter 3500 (2007-2009)
- Mercedes-Benz Sprinter 2500 (2019-2020)
- Mercedes-Benz Sprinter 3500 (2019-2023)
