CENTRIC 120.47024 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.47024 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 10.000 |
| Weight [cntrc] Lbs | 22.000 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.102 IN |
| Discard Thickness | 28.000 MM |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30.000 MM |
| Hat Finish | Painted |
| Overall Height | 2.248 IN |
| Overall Height | 57.100 MM |
| Outside Diameter | 316.500 MM |
| Outside Diameter | 12.461 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.283 IN |
| Center Hole Diameter | 58.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.516 IN |
| Stud/Lug Hole Diameter | 13.100 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890321354 |
CENTRIC 120.47024 Cross References
| Brand | Part Number |
|---|---|
| 980361, BD180004 | |
| ADVICS | F6F126U |
| N/A | 120.47024, BD180004, BD180004E, 44321GT, 44321, YH145751, 44321G, 26300AG000, 26300AG001, 26300AG002, 26300AG02A, 880361, 31408, 90013018 |
| NEOTEK | 106429GF |
| Neotek Premium Drums and Rotors | 106429GF |
| PRONTO | BR90049402 |
| RAYBESTOS | 980361, 980361FZN, 980361R, 980361R2 |
| Raybestos Brakes | 980361FZN, 980361R, 980361 |
| WAGNER | BD180004, BD180004E |
CENTRIC 120.47024 Fits Vehicles
- Subaru Forester (2014-2018)
- Subaru Outback (2010-2014)
- Subaru Legacy (2005-2014)
