(888) 312-8812 Login SignupLETRIKA MS293 Starter 12V, 10T, CW, PLGR, Letrika/MAHLE AZE46, 2.8kW, New
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LETRIKA MS293 Part Description
Manufacturer
Technical Data
| Product | Starter |
| Letrika P/N | IS1027 |
| Voltage | 12 V |
| Power | 3.2 kW |
| OEM P/N | 11.131.789 |
| MAHLE P/N | MS 293 |
| Description | AZE4655 |
| No. of pinion teeth | 10 |
| Module | 2.54 mm |
| Distance over two teeth | 12.29 mm |
| Outside diameter of pinion | 32 mm |
| Notes | Noseless version of starter |
| Oil sealed | |
| With reduction gear |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS1027 | 11.131.789 AZE4655 12V 3,2kW | MS 293 | Available |
| IS1027 | 11.131.771 AZE4652 12V 3,2kW | Superseded unit, see available P/N IS1027 | |
| IS1027 | 11.131.752 AZE4648 12V 3,2kW | Superseded unit, see available P/N IS1027 | |
| IS1027 | 11.131.221 AZE4620 12V 2,8kW | Superseded unit, see available P/N IS1027 | |
| IS1027 | 11.131.063 AZE4603 12V 2,8kW | Superseded unit, see available P/N IS1027 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.915.835 | MSX 1093 | Switch | 4 |
| 16.286.100 | MSX 1122 | Stator | 12 |
| 16.916.102 | MSX 1135 | Reduction gear | 8 |
| 16.915.982 | MSX 1159 | Lever | 7 |
| 16.908.751 | MSX 1229 | Fixing set | 11 |
| 16.907.753 | MSX 1366 | Armature | 9 |
| 16.908.746 | MSX 321 | Pinion with clutch | 6 |
| 16.908.753 | MSX 322 | Set of brushes | 14 |
| 16.285.493 | MSX 640 | Rear-end bracket | 15 |
| 16.911.900 | MSX 641 | Gear with clutch | 18 |
| 16.283.434 | MSX 70 | Drive end bracket | 1 |
| 16.908.752 | MX 5 | Brush holder | 13 |
LETRIKA MS293 Cross References
| Brand | Part Number |
|---|---|
| RCPST-17362, IS1027, MS 293 | |
| AES (USA) | 17362N |
| ATLAS COPCO | 91295372 |
| BOBCAT | 6632415 |
| BOSCH | SR 9975 X |
| CARGO | 110942 |
| CLARK | 2355695, 6632415 |
| DELCO REMY | 10461471, 10461473, 10461482, 10479628, 10479630, 1109208, 1113283, 1998364, 820089 |
| DENSO | 28000-8400, 28000-8401, 28000-8402, 28000-8403, 28000-8404, 9702809-840 |
| DIXIE | 246-25111, S-8278 |
| JOHN DEERE | AJ59342, RE19196, RE19275, RE41799, RE42730, RE49033, RE501693, RE505746, RE509658, RE516157, RE51694, RE529594, RE54092, RE551445, RE62916, SE501400, SE501428, SE501852, TY24305, TY25971, TY6688, TY6719 |
| LESTER | 17362, 17362A, 18475, 19655, 6577 |
| PRESTOLITE | 35261385, M100R2017SE |
| SPARE | X36196 |
| WAI | 17362N, 2-1750-ND |
| WILSON | 91-01-4362, 91-29-5106 |
