(888) 312-8812 Login SignupCENTRIC 125.50034 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 125.50034 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.50034 Specifications
Product Attributes
| Hat Id [cntrc] Mm | 142.700 |
| Misc Holes [cntrc] | 2 |
| Hat Id [cntrc] In | 5.618 |
| OEM Vane Count [cntrc] | 47 |
| Weight [cntrc] Lbs | 23.000 |
| Weight [cntrc] Kgs | 10.440 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Center Hole Diameter | 69.000 MM |
| Center Hole Diameter | 2.717 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320.000 MM |
| Overall Height | 1.953 IN |
| Overall Height | 49.600 MM |
| Hat Finish | Painted |
| Nominal Thickness | 1.142 IN |
| Nominal Thickness | 29.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00889590008517 |
CENTRIC 125.50034 Cross References
CENTRIC 125.50034 Fits Vehicles
- Hyundai Santa Fe Sport (2013-2018)
- Hyundai Santa Fe (2012)
- Kia Sorento (2014-2020)
