AUTOLITE 4194DP Part Description
Manufacturer
Product Description
Autolite 4194 Copper Non-Resistor Spark Plug
Features & Benefits
- One-Piece terminal stud provides a reliable high voltage electrical connection
- Specially engineered high nickel alloy center and ground electrode provides extended life.
- High alumina multi-rib insulator helps prevent flash-over which can lead to misfires
- It's multi-rib ceramic insulator reduces danger of flash-over while its copper-glass seal bonds the center electrode and terminal post, providing a gas-tight internal seal.
- It’s multi-rib ceramic insulator reduces danger of flash-over while its copper-glass seal bonds the center electrode and terminal post, providing a gas-tight internal seal.
- Heat-fused glass composite resistor center seal provides high performance EMI noise suppression and a 100 percent leak-proof seal
- Designed with a cold-formed steel shell precision rolled threads that provide greater durability and reduced wear.
- Solid copper core center electrode provides optimal thermal and electrical conductivity for better performance in all driving conditions
- High nickel alloy side electrode resists electrical and chemical wear providing excellent durability
- 2 year limited warranty
AUTOLITE 4194DP Specifications
Product Attributes
| Resistance | 1 82 |
| Ground Electrode Tip Design | Standard |
| Ground Electrode Core Material | Nickel |
| Electrical Terminal Type | Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | 0.025 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 16 MM |
| Seat Type | Flat |
| Reach | 0.5 IN |
| Thread Diameter | 10 MM |
| Insulator Material | Ceramic |
| Resistor Type | No |
| Ground Electrode Tip Material | Nickel |
| Center Electrode Design | Standard |
| Center Electrode Projection | Short Projection |
| Washer(s) Included | Yes |
| Grade Type | Regular |
| Hex Size | 5/8 IN |
| Manufacturer Heat Range | 12 |
| Skirt | Yes |
| Hex Type | Hex |
| Indexed | No |
| Pre-Gap Size | 0.6 MM |
| Reach | 12.7 MM |
| Thread Type Standard | Metric |
| Thread Size | M10 - 1.0 |
| Center Electrode Insulator Tip Projection | 1.7 MM |
| Washer Type | Flat |
| Thread Diameter | 10 MM |
| Center Electrode Insulator Tip Projection | 0.065 IN |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8511100000 |
| Warranty Time | 2 |
| Warranty Time UOM | YR |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00009100533401 |
| UNSPSC | 26101732 |
AUTOLITE 4194DP Cross References
| Brand | Part Number |
|---|---|
| ACDelco | S102F, S104F |
| Beru | 10 FR-4 AU |
| Bosch | U4A |
| Champion Spark Plug | 808, P-Z9HC, Z6, Z9Y |
| DENSO Auto Parts | 4000, IUF22, IUF24, U16FS-U, U16FSR-U, U16FSR-UB, U20FS-U, U20FSR-U, U22FS-U, U22FSR-U, U24FS-U, U24FSR-U |
| DOLMAR | 367 010 995 |
| Kawasaki | 92070-0023, 92070-1154, 920700023, 920701154 |
| Motorcraft | PV2, PV3 |
| NGK | 849, C6HSA, C7HIX, C7HSA, C7HVX, C8HA, C8HIX, C8HSA, C8HVX, CMR5H, CR4HSA, CR4HSB, CR5HIX, CR5HSA, CR5HSB, CR6HIX, CR6HS, CR6HSA, CR6HSB, CR7HIX, CR7HS, CR7HSA, CR7HSA-9, CR8HIX, CR8HIX-9, CR8HS, CR8HSA, CR8HVX |
| Odes | EG170-9-002, EG1709002 |
| Splitfire - Archived | SF419D |
| Suzuki | 09482-00406, 0948200406 |
| Torch | A6RTC, A6TC, A7RTC, A7TC, A8RTC, A8TC, T1137C |
| Yamaha | CR7-HSA00-00-00, CR7HSA000000 |
AUTOLITE 4194DP Fits Vehicles
- ODES Blazer 170 (2017)
- KYMCO Mongoose 90 R (2012-2013)
- E-TON Viper 90 (2007)
- E-TON YXL 150 (2001-2002)
- E-TON Yukon CXL 150 (2011)
- Bristol 400 (1946-1949)
- Yamaha YFM125 Raptor (2011-2013)
- E-TON Yukon II CXL 150 (2003-2010)
- Yamaha YFM90 Raptor (2009-2013)
- E-TON Viper 90R Silver Series (2009-2011, 2013)
- E-TON Viper 70 Silver Series (2009)
- E-TON Viper 90 Silver Series (2009-2011, 2013)
- KYMCO Mongoose 70 (2007-2010, 2013)
- Can-Am DS 50 (2007)
- Polaris Sawtooth (2006-2007)
- E-TON Viper 70 4-Stroke (2006-2008)
- E-TON Viper 90R 4-Stroke (2006-2011)
- E-TON Viper 70M 4-Stroke (2006-2007)
- Yamaha YFM80 Grizzly (2005-2008)
- E-TON Viper 150R (2005-2011)
- Yamaha YFM50 Raptor (2004-2008)
- Yamaha YFM125 Grizzly (2004-2013)
- KYMCO Mongoose 90 (2004-2010)
- Bombardier Quest 90 4-stroke (2004)
- Yamaha YFM80W Raptor (2002-2008)
- Bombardier DS90 4-Stroke (2002-2006)
- E-TON Yukon (2000-2001)
- Yamaha YFA-1 Breeze125 (1992-2004)
- Yamaha YFM100 Champ (1987-1991)
- Kawasaki KLF110 Mojave (1987-1988)
- Kawasaki KLT110 (1986)
- Honda TRX70 (1986-1987)
- Yamaha YFM80 Badger (1985-1988, 1992-2001)
- Honda ATC70 (1973-1974, 1978-1985)
- Bristol 406 (1958-1961)
- Bristol 405 (1954-1958)
- Arnolt-Bristol Bolide (1954-1963)
- Arnolt-Bristol Deluxe (1954-1961)
- Bristol 404 (1953-1956)
- Bristol 403 (1953-1955)
- Bristol 401 (1949-1953)
- Bristol 402 (1949-1953)
- Frazer Nash Sebring (1954-1955)
- Frazer Nash Fast Roadster (1949-1951)
- Frazer Nash Foursome Cabriolet (1949-1951)
- Frazer Nash Le Mans Coupe (1954-1956)
- Frazer Nash Targa Florio (1952-1954)
- Frazer Nash Mille Miglia (1949-1952)
- Frazer Nash Le Mans Replica (1949-1953)
- Aston Martin DB3 (1951-1952)
- Aston Martin DB2-4 (1953-1955)
- Aston Martin DB2 (1950-1953)
- Honda GL1800 Gold Wing Tour Automatic DCT (2018-2019)
- Honda GL1800 Gold Wing Tour (2018-2019)
- Honda GL1800 Gold Wing (2018-2019)
- Honda GL1800 Gold Wing Tour Airbag Automatic DCT (2018-2019)
- Honda GL1800 Gold Wing Automatic DCT (2018-2019)
- Kawasaki BR125 Z125 PRO SE (2018)
- Kawasaki BR125 Z125 PRO KRT Edition (2017-2018)
- Arctic Cat Alterra 90 (2017)
- Suzuki LT-Z50 QuadSport (2007-2009, 2017-2018)
- Kawasaki KLX140G (2017-2018)
- Yamaha YFZ50 (2017-2019)
- Kawasaki BR125 Z125 PRO (2017-2018)
- Polaris Sportsman 110 EFI (2016-2018)
- Polaris Outlaw 110 EFI (2016-2018)
- Polaris RZR 170 EFI (2015-2018)
- Arctic Cat 90 (2015-2016)
- Suzuki LT-Z90 QuadSport (2007-2009, 2014-2018)
- Kawasaki KFX90 (2007-2017, 2019)
- Kawasaki KFX50 (2007-2009, 2013-2017, 2019)
- Polaris RZR 170 (2014)
- KYMCO Like 200i LX (2013)
- Can-Am DS 70 (2008-2019)
- Honda CB72 Hawk 250 (1961)
- Honda CA95 Dream 150 (1959)
- Honda CB92 Benly Super Sport 125 (1959)
- Honda CB77 SuperHawk 305 (1961)
- Honda CL70 Scrambler (1969-1971)
- KYMCO People S 50 (2007-2009)
- KYMCO Super 8 150 (2009-2013)
- KYMCO People S 200 (2007-2010)
- KYMCO People S 125 (2007-2009)
- KYMCO People 150 (2002-2012)
- KYMCO Like 200i (2011-2013)
- KYMCO Filly 50 (2002-2004)
- KYMCO Agility 125 (2007-2013)
- Honda NCH50 Metropolitan (2013-2016)
- E-TON Matrix R4-150 (2009)
- E-TON Sport 150 (2009-2010)
- E-TON Beamer R4 (150) (2008-2009)
- Honda TRX90X (2009, 2012-2019)
- Polaris Sportsman 90 (2007-2014)
- Polaris Ranger RZR 170 (2011-2013)
- Polaris Outlaw 50 (2008-2018)
- Polaris Outlaw 90 (2007-2014)
- Can-Am DS 90 X (2008-2013)
- Can-Am DS 90 (2007-2013)
- Kawasaki KLX110L (2010-2014, 2016-2019)
- Arctic Cat DVX 90 SE (2009)
- Yamaha XV250 V Star 250 (2008-2018)
- Yamaha TTR110E (2008-2009, 2011-2013, 2015-2018)
- Suzuki DR-Z70 (2008-2009, 2015-2017)
- Kawasaki KLX140 (2008-2009, 2011-2019)
- Kawasaki KLX140L (2008-2009, 2011-2019)
- Arctic Cat 50 2x4 (2008)
- Honda TRX90EX Sportrax (2007-2008)
- Yamaha TTR50E (2006-2009, 2012-2018)
- Honda NSF100 (2006)
- Arctic Cat DVX 50 (2006)
- Arctic Cat DVX 90 (2006-2008, 2010-2017)
- Polaris Phoenix 200 (2005-2025)
- Honda CRF70F (2004-2009, 2011-2012)
- Honda CRF80F (2004-2009, 2011-2013)
- Honda CRF50F (2004-2009, 2011-2018)
- Honda CRF100F (2004-2009, 2011-2013)
- Arctic Cat 90 2x4 4-Stroke (2004-2008, 2010-2014)
- Yamaha TTR90E (2003-2007)
- Yamaha TTR125LE (2003-2009, 2011-2013, 2015-2018)
- Yamaha TTR125E (2003-2009)
- Suzuki DR-Z110 (2003-2005)
- Kawasaki KLX110 (2002-2014, 2017-2019)
- Arctic Cat 90 2x4 (2002-2004)
- Yamaha TTR90 (2000-2003)
- Yamaha TTR125L (2000-2007)
- Yamaha TTR125 (2000-2004)
- Honda XR50R (2000-2003)
- Honda XR70R (1997-2003)
- Yamaha XV250 Virago (1995-2007)
- Honda TRX90 Sportrax (1993-2006)
- Honda CB250 Nighthawk (1991-2008)
- Honda ZB50 (1988)
- Kawasaki EL250 Eliminator (1988-1989, 1991-1992)
- Yamaha XC125Z Riva (1986-1991)
- Kawasaki EX250F Ninja 250R (1986-2007)
- Yamaha XC125 Riva 125 (1985-1989, 1991-2001)
- Honda XR80R (1985-2003)
- Honda CH80 Elite (1985-2007)
- Honda XR100R (1985-2003)
- Honda CMX250C Rebel (1985-1987, 1996-2009, 2012-2016)
- Honda CM250C Custom (1982-1983)
- Honda XR100 (1981-1984)
- Honda XL80S (1980-1985)
- Honda CM200T Twinstar (1980-1982)
- Honda C70 (1980-1983)
- Honda Z50R (1979-1989, 1991-1999)
- Honda XR80 (1979-1984)
- Honda XL100S (1979-1985)
- Honda CM185T Twinstar (1978-1979)
- Honda XL75 (1977-1979)
- Honda XL70 (1974-1976)
- Honda XR75 (1973-1978)
- Honda SL70 (1971, 1973)
- Honda CT70 (1970-1980, 1982, 1991-1994)
- Honda Z50A (1972-1978)
- Honda QA50 (1971-1975)
- Honda PC50 (1970)
- Honda CA102 (1963)
- Honda S65 (1965)
- Honda CA105T (1963)
- Honda CA100 (1963)
