(888) 312-8812 Login SignupNGK SPARK PLUGS C7HSA NGK Standard Spark Plug
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS C7HSA Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS C7HSA Specifications
Product Attributes
| Part Number | C7HSA |
| Stock Number | 4629 |
| Short Style Spark Plug | No |
| Service Number | C7HSA |
| Resistance | 0.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 1.88 IN |
| Manufacturer Heat Range | 7 |
| Seat Type | Flat |
| Reach | 0.500 IN |
| Thread Diameter | 0.394 IN |
| Insulator Material | Ceramic |
| Resistor Type | No |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.06 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.7 MM |
| Insulator Height | 47.7 MM |
| Reach | 12.7 MM |
| 6648 | 0.0 MM |
| Thread Size | M10 - 1.0 |
| Center Electrode Insulator Tip Projection | 1.65 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295146293 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS C7HSA Cross References
| Brand | Part Number |
|---|---|
| ACDelco | S102F |
| AUTOLITE | 4194DP, 4194 |
| Autolite | 4193, 2795 |
| CHAMPION | 808 |
| Champion Spark Plug | Z8, P-Z7HC |
| DENSO Auto Parts | 4006, U22FS-U, U22FS |
| Honda | 98056-57713 |
| Kawasaki | 92070-1107 |
| Magneti Marelli | CU7N |
| Motorcraft | PV2 |
| N/A | C7HSA |
| NGK | 4629 |
| SYM | 98056-57713-0A |
| Suzuki | 99000-69571 |
| Torch | A7C |
| Yamaha | 94700-00835-00-IV, 94701-00254, 94703-00254 |
NGK SPARK PLUGS C7HSA Fits Vehicles
- LEM RX 150 Motard (2011)
- LEM DX150 Motard 40th (2013)
- LEM DX150 40th (2013)
- Honda CL70 Scrambler (1969-1972)
- KYMCO Vitality 50 (2004-2007)
- KYMCO Filly 50 (2002-2004)
- LEM DX150 (2010-2013)
- LEM RX 150 (2010)
- LEM DX150 Motard (2010-2013)
- E-TON Yukon II CXL 150 (2002-2010)
- E-TON Viper 150R (2005-2010)
- E-TON Yukon (2000-2001)
- Yamaha YFA-1 Breeze125 (1989-1998)
- Yamaha YFM100 Champ (1987-1991)
- Honda XR100 (1981)
- Honda XL80S (1980-1981)
- Honda CM200T Twinstar (1980-1981)
- Honda C70 (1980-1981)
- Honda XR80 (1979-1981)
- Honda CM185T Twinstar (1978-1979)
- Honda XL75 (1977-1979)
- Honda XL70 (1974-1976)
- Honda XR75 (1973-1978)
- Honda ATC70 (1973-1974, 1978-1981)
- Honda SL70 (1971, 1973)
- Honda CT70 (1970-1980)
- Honda QA50 (1971-1975)
- Honda S65 (1965)
- Honda CA100 (1963)
- Honda CA102 (1963)
- Honda CA105T (1963)
- Honda CA110 (1963)
NGK SPARK PLUGS C7HSA Customer Reviews
No reviews yet
Be the first to review this product!
NGK SPARK PLUGS C7HSA Questions & Answers
No questions yet
Be the first to ask a question about this product!
