(888) 312-8812 Login SignupSPECTRA PREMIUM TOP06B Engine Oil Pan
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
SPECTRA PREMIUM TOP06B Part Description
93-88 TOYOTA COROLLA [DLX ALL TRAC/SR5 ALL TRAC] (L4 1.6L)
SPECTRA PREMIUM TOP06B Specifications
Product Attributes
| California_prop 65 Message | Y |
| Material | Cold Rolled Steel (EDDQ) |
| Capacity | 2.9000 LT |
| Length | 457.0000 MM |
| Maximum Width | 225.0000 MM |
| Color | Black |
| Oil Level Sensor Port | Yes |
| Baffled | yes |
| Crank Shaft Wiper Included | No |
| Maximum Depth | 137.0000 MM |
| Dipstick Port | No |
| Drain Plug Included | Yes |
| Engine Oil Cooler Return Fitting | No |
| Kick Out Type Pan | No |
| Pickup Included | No |
| Sump Location | Front |
| Sump Type | Wet |
| Windage Tray Included | No |
| Finish | Black Powder Coating |
| Gasket Or Seal Included | No |
| Mounting Hole Quantity | 21 |
| Drain Thread Size | M14 X 1.5 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8409914000 |
| Warranty Time UOM | MO |
| Warranty Time | 36 |
| Country of Origin (Primary) | CA |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00671607608144 |
| VMRS Code | 045013001 |
| UNSPSC | 26101735 |
SPECTRA PREMIUM TOP06B Cross References
SPECTRA PREMIUM TOP06B Fits Vehicles
- Toyota Corolla (1988-1993)
SPECTRA PREMIUM TOP06B Customer Reviews
No reviews yet
Be the first to review this product!
SPECTRA PREMIUM TOP06B Manufacturer Information
When it comes to engine management, heavy-duty cooling, undercar, and classic car products, Spectra Premium has always been the Premium Choice since 1989. In the last 30 years, Spectra Premium has solidified its position as a world leader in the production of steel fuel tanks. Guided by the company's three core values—trust, collaboration, and creativity—its Mobility Solutions division continues to develop, manufacture, and sell advanced technologies that support sustainable mobility. Spectra's passion for innovation is evident from the early phases of the design process to the final stages of product manufacturing and testing. With decades of manufacturing expertise, OE design, and state-of-the-art technologies, Spectra Premium's automotive sensors, emission control components, radiators, air coolers, body panels, fuel tanks, and many other products are definitely built to last.
SPECTRA PREMIUM TOP06B Questions & Answers
No questions yet
Be the first to ask a question about this product!
