MONROE 37163 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 37163 Specifications
Product Attributes
| Lower Mount Code | XP5 |
| Upper Mount Code | S5 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 10.25 IN |
| Dust Shield Material | Metal |
| Extended Length | 15 in |
| Gas Charged | Yes |
| Lower Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.1/2" Pin Length (Hole Center to Center) |
| Parts Pack(s) | P01167 |
| Travel Length | 4.75 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Compressed Length | 260.3 MM |
| Extended Length | 381 MM |
| Travel Length | 120.6 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598156532 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37163 Cross References
| Brand | Part Number |
|---|---|
| 37163ST | |
| Chevrolet | 22064861, 22064862, 22064863, 22064864, 22064867, 22064868, 22400058, 22400365, 22400563, 88983817, 89038652, 89038653, 89038654 |
| FCS | 341599 |
| FCS AUTO PARTS | 341599 |
| GABRIEL | G63817, G63783 |
| GMC | 22064861, 22064862, 22064863, 22064864, 22064867, 22064868, 22400058, 22400365, 22400563, 88983817, 89038652, 89038653, 89038654 |
| KYB | 344402, KG54339, 565102, KG54340, 565101, 344383 |
| KYB AMERICA LLC. | 344402 |
| MERITOR | MG61158 |
| NAPA Shocks | 37163 |
| POWER10 PARTS | SSA-G63817 |
MONROE 37163 Fits Vehicles
- GMC Sierra 2500 (1999-2004)
- Chevrolet Silverado 2500 (1999-2004)
