MONROE 37116 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 37116 Specifications
Product Attributes
| Lower Mount Code | L1 |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 10.25 IN |
| Dust Shield Material | Metal |
| Extended Length | 14.875 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Parts Pack(s) | P01135 |
| Travel Length | 4.625 in |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 260.3 MM |
| Extended Length | 377.8 MM |
| Travel Length | 117.5 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing |
| Lower Mount Code | L1 |
| Upper Mount Code | S4 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598156068 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37116 Cross References
| Brand | Part Number |
|---|---|
| 37116ST, FT4Z5823942DF | |
| AUTOZONE | TS34-31391B |
| AutoZone | TS3431391B |
| Duralast | TS3431391B |
| FCS | 342827 |
| FCS AUTO PARTS | 342827 |
| Ford | 3U2Z18125RA, 8C2Z18124A, 8C2Z18124B, 8C2Z18125A, 8C2Z18125B, F2UZ18124B, F2UZ18124D, F2UZ18125D, F4UZ18125C, F5UZ18124A, F5UZ18124B, F5UZ18125A, F7UZ18125AA, F7UZ18125AB, F8AZ18125BB |
| GABRIEL | G63622 |
| KYB | 554369, 344370, 345080, 565014, 565120, KG5497 |
| MERITOR | MG60182 |
| MasterPro Shocks and Struts | FD107 |
| NAPA Proformer | SH81744 |
| NAPA Shocks | 37116 |
| OEM | 8C2Z18124B, 8C2Z18124A |
| PRT | 175450 |
| SENSEN | 12140177 |
| Top Quality | 7837116 |
MONROE 37116 Fits Vehicles
- Ford E-150 Econoline (2008)
- Ford E-150 (2008-2014)
- Ford E-250 (2003-2006)
- Ford E-250 Econoline (1992-2002)
