(888) 312-8812 Login SignupMONROE 911302 Reflex Suspension Shock Absorber
Tap to view 5 more
MSRP: $199.01
$9899
Save $100.02
Limited availability at this price!
In Stock
Get it by Thursday, Feb 26
MONROE 911302 Part Description
Manufacturer
Product Description
Reflex Suspension Shock Absorber
Features & Benefits
- IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to run cooler
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 911302 Specifications
Product Attributes
| Lower Mount Code | LS38 |
| Upper Mount Code | LS38 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 18.43 IN |
| Dust Shield Material | Metal |
| Extended Length | 28.64 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 10.21 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 38.1MM Sleeve OAL |
| Compressed Length | 468.1 MM |
| Extended Length | 727.5 MM |
| Travel Length | 259.3 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS38 |
| Upper Mount Code | LS38 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598064066 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 911302 Cross References
| Brand | Part Number |
|---|---|
| 911302MM, 829352491881 | |
| AUTOZONE | TS34-32232B |
| AutoZone | TS3432232B |
| Duralast | TS3432232B |
| FCS | DT342887, 342789 |
| FCS AUTO PARTS | DT342887 |
| Ford | 9L3Z18124BE, 9L3Z18124CE, 9L3Z18124DE, 9L3Z18124EE, 9L3Z18124FE, 9L3Z18124M, 9L3Z18125A, 9L3Z18125B, 9L3Z18125C, 9L3Z18125D, 9L3Z18125E, 9L3Z18125F, AL3Z18124A, AL3Z18124AA, AL3Z18124BA, AL3Z18124CA, AL3Z18124DA, AL3Z18124EA, AL3Z18124FA, AL3Z18124GA, AL3Z18124RB, AL3Z18124SB, AL3Z18124TA, AL3Z18125D, AL3Z18125E, AL3Z18125G, AL3Z18125H, AL3Z18125K, AL3Z18125L, BL3Z18124C, BL3Z18124F, BL3Z18124H, BL3Z18124J, BL3Z18125C, BL3Z18125F, BL3Z18125H, BL3Z18125J, BL3Z18125K, BL3Z18125L, CL3Z18124A, CL3Z18124B |
| GABRIEL | G64079 |
| KYB | 349108, 554373, 5650006 |
| KYB AMERICA LLC. | 349108, 554373 |
| MasterPro Shocks and Struts | FD170 |
| Monroe Shocks & Struts | 33237, 550062, 210462 |
| NAPA Shocks | 911302, 94379, NS911302 |
| PRT | 173932 |
| Rancho | RS5384, RS55384 |
| SACHS NORTH AMERICA | 316580 |
| SENSEN | 12140169 |
| Sachs | 316580 |
| Top Quality | 78911302 |
| Ultra Spring Seat | G64079 |
MONROE 911302 Fits Vehicles
- Ford F-150 (2009-2013)
