CENTRIC 120.33144 Part Description
Manufacturer
Product Description
Premium Brake Rotor
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.33144 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 144.100 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 24.900 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 11.290 |
| Vane Style [cntrc] | Pillar |
| Hat Id [cntrc] In | 5.673 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 27.000 MM |
| Discard Thickness | 1.063 IN |
| Nominal Thickness | 30.000 MM |
| Nominal Thickness | 1.181 IN |
| Hat Finish | Painted |
| Overall Height | 49.800 MM |
| Overall Height | 1.961 IN |
| Outside Diameter | 340.000 MM |
| Outside Diameter | 13.386 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 65.000 MM |
| Center Hole Diameter | 2.559 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.200 MM |
| Stud/Lug Hole Diameter | 0.598 IN |
CENTRIC 120.33144 Cross References
CENTRIC 120.33144 Fits Vehicles
- Volkswagen Jetta (2022-2023)
- Volkswagen GTI (2022-2023)
- Volkswagen Arteon (2022-2023)
- Volkswagen Golf (2019-2021)
