(888) 312-8812 Login SignupCENTRIC 125.33102 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 4 more
$12849
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 19
CENTRIC 125.33102 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.33102 Specifications
Product Attributes
| Notes [cntrc] | Vented Hat |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 15.500 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 7.050 |
| Misc Holes [cntrc] | 5 |
| Discard Thickness | 20.000 MM |
| Discard Thickness | 0.787 IN |
| Nominal Thickness | 0.858 IN |
| Nominal Thickness | 21.800 MM |
| Hat Finish | Painted |
| Overall Height | 42.200 MM |
| Overall Height | 1.661 IN |
| Outside Diameter | 309.900 MM |
| Outside Diameter | 12.201 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 68.000 MM |
| Center Hole Diameter | 2.677 IN |
| Stud/Lug Hole Diameter | 0.602 IN |
| Stud/Lug Hole Diameter | 15.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 112.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.421 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890729310 |
CENTRIC 125.33102 Cross References
| Brand | Part Number |
|---|---|
| ATE BRAKE PRODUCTS | 422212 |
| N/A | 34288, 880232, 880517, BD126337, DDF1934C, DF4269, 34288G, 90073040, 4E0615601A, 4E0615601K, 3D0615601D, 4E0615601D, 980232, 980232P, 980517 |
CENTRIC 125.33102 Fits Vehicles
- Volkswagen Phaeton (2004-2006)
- Audi A8 Quattro (2004-2010)
