(888) 312-8812 Login SignupSEALED POWER 400AP30 Sealed Power 400AP 30 Engine Piston Set
$41992
Package Price for 8 Units
@ $52.49 per unit
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Mar 9
SEALED POWER 400AP30 Part Description
Manufacturer
Product Description
Engine Piston Set
Features & Benefits
- Cast with FM132 Eutectic proprietary alloy
- Performance & dependability of original equipment pistons
- High quality aluminum
- Utilizes ISO & QS certified manufacturing
- Meets or exceeds OEM specifications
SEALED POWER 400AP30 Specifications
Product Attributes
| Oversized | Yes |
| Top Compression Ring Thickness | 0.0781 IN |
| Second Compression Ring Thickness | 0.0781 IN |
| Oil Ring Thickness | 0.1875 IN |
| Piston Pin Outside Diameter | 0.9275 IN |
| Assembly Lubricant Included | No |
| Bore Diameter | 4.1250 IN |
| Piston Material | Cast Aluminum |
| Compression Height | 1.540 IN |
| Dome Volume CC | Negative 025.0 |
| Head Illustration | 28 |
| Head Type | Recessed Head .160 deep x 3.445 dia. - 8.5:1 C.R. |
| Minimum Clearance | 0.001 @ 1.830 from top of head |
| Oversized Amount | 0.030 IN |
| Part Description | Engine Piston |
| Pin Offset (Inch) | 0.03 |
| Pin Offset (MM) | 0.762 |
| Pin Type | P |
| Weight W Pin Gram | 00785.+/- 00. |
| Bore Diameter | 104.78 MM |
| Grade Type | Premium |
| Piston Pin Outside Diameter | 23.559 MM |
| Grade Type | Premium |
| Piston Head Type | Recessed |
Additional Information
| Country of Origin (Primary) | IN |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00614046639836 |
SEALED POWER 400AP30 Cross References
| Brand | Part Number |
|---|---|
| Clevite | TC1852.030, TC1852030 |
| Enginetech | P1546(8)030 |
| N/A | 400AP 30, 1443.030, Z8308 030 |
| SEALED POWER | 400AP30 |
| Silvolite | 1443030 |
| Zollner | Z8308030 |
SEALED POWER 400AP30 Fits Vehicles
- GMC K3500 (1979-1980)
- GMC K35 (1977-1978)
- GMC K2500 Suburban (1979-1980)
- GMC K25 Suburban (1975-1978)
- GMC K2500 (1979-1980)
- GMC K25 (1975-1978)
- GMC K1500 Suburban (1979-1980)
- GMC K15 Suburban (1975-1978)
- GMC K1500 (1979-1980)
- GMC K15 (1975-1978)
- GMC Jimmy (1975-1979)
- GMC G3500 (1979-1980)
- GMC G35 (1975-1978)
- GMC G2500 (1979-1980)
- GMC G25 (1975-1978)
- GMC G1500 (1979)
- GMC G15 (1976)
- GMC C3500 (1979)
- GMC C35 (1976-1978)
- GMC C2500 Suburban (1980)
- GMC C25 Suburban (1978)
- GMC C2500 (1979)
- GMC C25 (1976-1978)
- GMC C1500 (1979-1980)
- GMC C15 (1976, 1978)
- Chevrolet Townsman (1970-1972)
- Chevrolet Kingswood (1970-1972)
- Chevrolet Chevelle (1970-1973)
- Chevrolet Brookwood (1970-1972)
- Chevrolet Biscayne (1970-1972)
- Pontiac Strato-Chief (1970)
- Pontiac Parisienne (1970-1974)
- Pontiac Laurentian (1970-1974)
- Chevrolet Estate (1970)
- GMC Sprint (1974-1976)
- Chevrolet P30 (1976)
- Chevrolet P10 (1977)
- Chevrolet Monte Carlo (1970-1976)
- Chevrolet Malibu (1973-1976)
- Chevrolet Laguna (1973-1976)
- Chevrolet K30 (1977-1980)
- Chevrolet K20 Suburban (1975-1980)
- Chevrolet K20 (1975-1980)
- Chevrolet K10 Suburban (1975-1979)
- Chevrolet K10 (1975-1980)
- Chevrolet Impala (1970-1976)
- Chevrolet G30 (1975-1980)
- Chevrolet G20 (1975-1980)
- Chevrolet G10 (1976)
- Chevrolet El Camino (1973-1976)
- Chevrolet Caprice (1970-1976)
- Chevrolet C30 (1976-1978)
- Chevrolet C20 Suburban (1976-1980)
- Chevrolet C20 (1976-1980)
- Chevrolet C10 (1976-1980)
- Chevrolet K5 Blazer (1975-1979)
- Chevrolet Bel Air (1970-1975)
