Need help? We're here!
(888) 312-8812 Login SignupDONALDSON M122300 MUFFLER, OVAL,
$97399
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
DONALDSON M122300 Part Description
DONALDSON M122300 Specifications
Product Attributes
| Body Length | 31.75 in |
| Overall Length | 42.50 in |
| Attenuation Hr | 15 dBA |
| Attenuation Lr | 10 dBA |
| Back Pressure High-range | Hg2.99 inch Hg) |
| Back Pressure Low-range | Hg0.98 inch Hg) |
| Back Pressure Mid-range | Hg2.01 inch Hg) |
| Body Diameter Maximum | 15.00 in |
| Body Diameter Minimum | 10.00 in |
| Inlet Clock Position | 12/31/1899 3:00:00 AM |
| Inlet Diameter | 6.04 in |
| Outlet Clock Position | 12/31/1899 9:00:00 AM |
| Outlet Diameter | 6.04 in |
| Rated Flow Hr | 105.8 m³/min (3736 cfm) |
| Rated Flow Lr | 61.1 m³/min (2158 cfm) |
| Rated Flow Mr | 86.4 m³/min (3051 cfm) |
| Style | Style 2 |
DONALDSON M122300 Cross References
We have 7 alternatives for the M122300 by DONALDSON:
DONALDSON M122300 Manufacturer Information
For more than 100 years, Donaldson® has provided effective solutions to complex filtration challenges in various industries. Fleet managers worldwide have relied on Donaldson’s wide range of filtration products to ensure their trucks operate at peak efficiency and reduce expenses and maintenance downtime in the long run. These products include air intake filters and cleaners, cabin air filters, coolant filters, fuel filters and water separators, transmission filters, exhaust filtration products, and so much more. Each Donaldson filtration product is engineered for durability and performance that matches that of the original. Whether they are long-haul trucks, school buses, dump trucks, or other commercial vehicles, Donaldson filtration products will help keep them running smoothly.
