RAYBESTOS 782636R2 Part Description
Manufacturer
Product Description
Raybestos R-Line+ Brake Rotor
Features & Benefits
- Painted Hat and Edges
- Top-Notch Surface Finish
- Superior surface finish for consistent braking.
- OE Vane Design
- OE vane design and plate thickness for heat capacity and strength.
- Advanced Metallurgy
- Advanced metallurgy for structural strength and heat transfer.
- Low Initial Lateral Run-out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free braking.
- Precision Balance
- Precision balance for vibration free performance.
Raybestos R-Line+ Brake Rotor
RAYBESTOS 782636R2 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.492 IN |
| Discard Thickness | 1.516 IN |
| Inside Diameter | 10.039 IN |
| Mounting Bolt Hole Circle Diameter | 7.087 IN |
| Mounting Bolt Hole Diameter | 0.64 IN |
| Mounting Bolt Hole Quantity | 8 |
| Nominal Thickness | 1.575 IN |
| Outside Diameter | 13.976 IN |
| Overall Height | 5.906 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 8 |
| Surface Type | Smooth |
| Stud/Lug Hole Diameter | 0.64 IN |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 114.1 MM |
| Discard Thickness | 38.5 MM |
| Inside Diameter | 255 MM |
| Mounting Bolt Hole Circle Diameter | 180 MM |
| Mounting Bolt Hole Diameter | 16.25 MM |
| Nominal Thickness | 40 MM |
| Outside Diameter | 355 MM |
| Overall Height | 150 MM |
| Stud/Lug Hole Diameter | 16.25 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213447583 |
RAYBESTOS 782636R2 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 177-1278 |
| Advance Auto Parts | YH720509P |
| AutoZone | 72022, 72022DG |
| BrakeBest | 580895RGS |
| Centric Parts | 120.66083, 121.66083, 320.66083 |
| Dura Corp | BR901894, BR901894-01 |
| DuraGo | BR901894, BR901894-01 |
| General Motors | 13512717, 13550274 |
| Qualis | 41359 |
| WORLDPAC | 1407-720509, 1427-732835 |
| Winhere | 6622756 |
RAYBESTOS 782636R2 Fits Vehicles
- GMC Sierra 3500 HD (2020-2025)
- Chevrolet Silverado 3500 HD (2020-2025)
