RAYBESTOS 582458R2 Part Description
Manufacturer
Product Description
Raybestos R-Line+ Brake Rotor
Features & Benefits
- Painted Hat and Edges
- Top-Notch Surface Finish
- Superior surface finish for consistent braking.
- OE Vane Design
- OE vane design and plate thickness for heat capacity and strength.
- Advanced Metallurgy
- Advanced metallurgy for structural strength and heat transfer.
- Low Initial Lateral Run-out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free braking.
- Precision Balance
- Precision balance for vibration free performance.
Raybestos R-Line+ Brake Rotor
RAYBESTOS 582458R2 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.1 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.1 IN |
| Inside Diameter | 8.7 IN |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Diameter | 0.6 IN |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.2 IN |
| Outside Diameter | 13.5 IN |
| Overall Height | 2.3 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| Surface Type | Smooth |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 78.7 MM |
| Discard Thickness | 28.0 MM |
| Inside Diameter | 220.5 MM |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 16.0 MM |
| Nominal Thickness | 30.0 MM |
| Outside Diameter | 343.0 MM |
| Overall Height | 58.6 MM |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Weight [cntrc] Kgs | 13.2 |
| Weight [cntrc] Lbs | 29.2 |
| Maximum Brake Diameter (Discard) | 343.0 MM |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Grade Type | Regular |
| Material | Cast Iron |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213446227 |
RAYBESTOS 582458R2 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH653387P |
| AutoZone | 72099DL, 72099DG, 72099SD |
| BrakeBest | 582458RGS |
| Cadillac | 13553983, 84879622, 87839222, 87869716 |
| Centric Parts | 120.66080, 121.66080 |
| Chevrolet | 13553983, 84879622, 87839222, 87869716 |
| Dura Corp | BR901832, BR901832-01 |
| DuraGo | BR901832, BR901832-01, BR901832-02 |
| Dynamic Friction Company | 600-47080, 604-47080 |
| GMC | 13553983, 84879622, 87839222, 87869716 |
| General Motors | 13514522, 13553983 |
| Qualis | 41355 |
| TopNotch | TN582458GEO |
| WORLDPAC | 1407-653387, 1427-653420 |
| Wagner Brake | BD180849E |
| Winhere | 6622330 |
RAYBESTOS 582458R2 Fits Vehicles
- GMC Sierra 1500 Limited (2019, 2022)
- GMC Yukon XL (2021-2024)
- Chevrolet Suburban (2021-2024)
- GMC Yukon (2021-2024)
- Cadillac Escalade ESV (2021-2024)
- Chevrolet Tahoe (2021-2024)
- Chevrolet Silverado 1500 LTD (2022)
- Cadillac Escalade (2021-2024)
- GMC Sierra 1500 (2019-2024)
- Chevrolet Silverado 1500 (2019-2024)
