RAYBESTOS 96088 Raybestos Specialty - Street Performance Brake Rotor

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 96088 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

1991-1988 Honda Civic Front, 1991-1988 Honda CRX Front, 1989-1986 Acura Integra Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 96088 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.404 IN
Center Hole Diameter 61.05 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 0.669 IN
Discard Thickness 17 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 3.937 IN
Mounting Bolt Hole Circle Diameter 100 MM
Mounting Bolt Hole Diameter 3.937 IN
Mounting Bolt Hole Diameter 100 MM
Mounting Bolt Hole Quantity 4
Nominal Thickness 0.75 IN
Nominal Thickness 19.05 MM
Outside Diameter 9.515 IN
Outside Diameter 241.7 MM
Overall Height 1.735 IN
Overall Height 44.05 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 4
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00030999234346

RAYBESTOS 96088 Cross References

BrandPart Number
190-6363
ADVANCE AUTO PARTS141424, YH141424, YH141424C
ALTROM IMPORTSA03178
AMERICAN REMANUFACTURED789-08013, 89-08013
AUTOPART INTERNATIONAL78559
AUTOSPECIALTYJBR304, JBR304E
AUTOXTRA61859, AX3178
AUTOZONE3178, 3178B, 3178DG, DL3178
BECK/ARNLEY080-2179, 083-2179
BENDIX141424
BOSCHRBR3178
BRAKE HEADQUARTERSBR02013
BRAKE PRO4619353, 4619374
BRAKEBEST81-61859, 96088, 96088R, 96088RGS, BD61859
BREMBO09.5023.10, 25280
BrakeBest96090RGS
Bridgestone7075418
CALIFORNIA DRUM & ROTOR61859
CENTRIC120.40013, 121.40013, 125.40013, 125.40013CRY, 126.40013CSL, 126.40013CSR, 126.40013SL, 126.40013SR, 127.40013CL, 127.40013CR, 127.40013L, 127.40013R, 128.40013CL, 128.40013CR, 128.40013L, 128.40013R, 320.40013, 320.40013F
CENTURY9374
CONTINENTAL-CONTITECHCW19701
Casting Numbers210461-C, 31781, 325070, 6821
Centric Parts120.40013, 121.40013, 125.40013, 125.40013CRY, 126.40013CSL, 126.40013CSR, 126.40013SL, 126.40013SR, 127.40013CL, 127.40013CR, 127.40013L, 127.40013R, 128.40013CL, 128.40013CR, 128.40013L, 128.40013R, 320.40013, 320.40013F
DAYTON WALTHERD7938
DELPHIRB64
DURA CORPBR3178
DuraGoBR3178
EIS BRAKESD17263
EUROROTORHO523
FADE FREE61859
GIRLINGGR811
GREN43402
GUARDIAN52-61859
HONDA45251SB2780, 45251SB2781, 45251SB2782
INTERBRAKESHO141V
ITM ENGINE COMPONENTS1600920
MAGMA PRODUCTSPSR263014
MCI3901
MIDASBR1561
MIGHTY DISTRIBUTING SYSTEM3178
NEWTEK AUTOMOTIVE3178
Newtek Automotive USA3178
PARTS MASTERP61859
PRONTOBR3178
QUALIS3178
QUALITEE INTERNATIONAL64-71-010
QUALITY BRAND3178
QUINTON HAZELLBDC3591
ROADMATES526590
ROCKHILL3178
STANDARD ROTORS AND DRUMS3178
THE UNIVERSAL GROUP115780
TRUSTAR471010, R71010
TRWDF1963S
UAP3178
Universal115780
VERA3405078
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX50423
WAGNERBD61859
WAGNER BRAKEBD125011, BD61859, SB96088
WINHEREYH2003
WORLDPAC1427-732126

RAYBESTOS 96088 Fits Vehicles

  • Honda CRX (1988-1991)
  • Honda Civic (1988-1991)
  • Acura Integra (1986-1989)
