CENTRIC 125.40013 Part Description
Manufacturer
Product Description
Premium High-Carbon Rotor
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.40013 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 9.750 |
| Misc Holes [cntrc] | 4 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.430 |
| Stud/Lug Hole Diameter | 12.700 MM |
| Stud/Lug Hole Diameter | 0.500 IN |
| Stud/Lug Hole Quantity | 4 |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Center Hole Diameter | 2.402 IN |
| Center Hole Diameter | 61.000 MM |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 9.528 IN |
| Outside Diameter | 242.000 MM |
| Overall Height | 1.732 IN |
| Overall Height | 44.000 MM |
| Hat Finish | Painted |
| Nominal Thickness | 0.748 IN |
| Nominal Thickness | 19.000 MM |
| Discard Thickness | 17.000 MM |
| Discard Thickness | 0.669 IN |
CENTRIC 125.40013 Cross References
CENTRIC 125.40013 Fits Vehicles
- Honda CRX (1988-1991)
- Honda Civic (1988-1991)
- Acura Integra (1986-1989)
