RAYBESTOS 980330 Raybestos Specialty - Street Performance Brake Rotor

$77.49

Limited availability at this price!

1 Day Lead Time

Get it by Thursday, Mar 12
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

RAYBESTOS 980330 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2011-2003 Saab 9-3 Front, 2010 Saab 9-3X Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 980330 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.756 IN
Center Hole Diameter 70 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 0.866 IN
Discard Thickness 22 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.331 IN
Mounting Bolt Hole Circle Diameter 110 MM
Mounting Bolt Hole Diameter 0.546 IN
Mounting Bolt Hole Diameter 13.85 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.98 IN
Nominal Thickness 24.9 MM
Outside Diameter 11.22 IN
Outside Diameter 285 MM
Overall Height 1.657 IN
Overall Height 42.1 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) IT
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352279151

RAYBESTOS 980330 Cross References

BrandPart Number
829352279151, 120.38016
ADVANCE AUTO PARTSYH145623, YH145623C
ATE BRAKE PRODUCTS425141, SP25141
AUTOXTRAAX900432
AUTOZONE34269, 34269DG
BENDIX145623
BRAKEBEST45011188, 980330, 980330FZN, 980330R, 980330RGS
BREMBO09.9165.10, 09.9165.11
Brembo09.9165.1X
CENTRIC120.38016, 121.38016, 125.38016, 125.38016CRY, 126.38016CSL, 126.38016CSR, 126.38016SL, 126.38016SR, 127.38016L, 127.38016R, 128.38016L, 128.38016R, 320.38016H
CONTINENTAL-CONTITECHCW25141
Casting Numbers211705-C
Centric Parts120.38016, 121.38016, 125.38016, 125.38016CRY, 126.38016CSL, 126.38016CSR, 126.38016SL, 126.38016SR, 127.38016L, 127.38016R, 128.38016L, 128.38016R, 320.38016H
DURA CORPBR34269, BR900432
DuraGo900432, BR900432
MIGHTY DISTRIBUTING SYSTEM34269
NAPA BRAKESSDK6060
NEWTEK AUTOMOTIVE34269
Newtek Automotive USA34269
OPEL569003
PILENGAV764
POWERSTOPEBR678EVC
PROMAX14-34269
PRONTOBR900432
QUINTON HAZELLBDC5412
Qualis34269
SAAB9156807, 93171497
TRWDF4293
UAP34269
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51720
WAGNERBD126145
WAGNER BRAKEBD126145
WINHERE6620163

RAYBESTOS 980330 Fits Vehicles

  • Cadillac BLS (2007-2008)
  • Saab 9-3X (2010)
  • Saab 9-3 (2003-2011)
