RAYBESTOS 96940 Raybestos Specialty - Street Performance Brake Rotor

$138.99

Limited availability at this price!

1 Day Lead Time

Get it by Tuesday, Mar 10
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
This item will ship about 1 day after the date of purchase

RAYBESTOS 96940 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2005-2002 Mercedes-Benz ML500 Rear, 2001-2000 Mercedes-Benz ML430 Rear, 2003-2000 Mercedes-Benz ML55 AMG Rear

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 96940 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.64 IN
Center Hole Diameter 67.05 MM
Conventional Or Drum-In-Hat Type Rotor Drum-In-Hat
Discard Thickness 0.484 IN
Discard Thickness 12.3 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.409 IN
Mounting Bolt Hole Circle Diameter 112 MM
Mounting Bolt Hole Diameter 4.409 IN
Mounting Bolt Hole Diameter 112 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.547 IN
Nominal Thickness 13.9 MM
Outside Diameter 13.03 IN
Outside Diameter 330.95 MM
Overall Height 2.165 IN
Overall Height 55 MM
Salability Restrictions No
Solid Or Vented Type Rotor Solid
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00747730912264

RAYBESTOS 96940 Cross References

BrandPart Number
747730912264, 120.35043
ADVANCE AUTO PARTSYH145331, YH145331C
ALTROM IMPORTS1634230012
AMERICAN REMANUFACTURED89-74043
ATE BRAKE PRODUCTS414111, SP14111
AUTOZONE34175, 34175DG
BENDIX145331
BRAKEBEST36010942, 96940, 96940R, 96940RGS, BD126239
BREMBO08.5174.30, 08.7607.10, 25528
Brembo08.7607.11
CENTRIC120.35043, 121.35043, 125.35043, 125.35043CRY, 126.35043CSL, 126.35043CSR, 126.35043SL, 126.35043SR, 127.35043L, 127.35043R, 128.35043R, 128.35043CL, 128.35043CR, 128.35043L, 320.35043H
CONTINENTAL-CONTITECHCW14111
Casting Numbers211295-C, 325933
Centric Parts120.35043, 121.35043, 125.35043, 125.35043CRY, 126.35043CSL, 126.35043CSR, 126.35043SL, 126.35043SR, 127.35043L, 127.35043R, 128.35043CL, 128.35043CR, 128.35043L, 128.35043R, 320.35043H
DURA CORPBR34175
DuraGoBR34175
MERCEDES-BENZ1634230012
MIGHTY DISTRIBUTING SYSTEM34175
NAPA BRAKESSDK6318
NEOTEK106574GF
NEWTEK AUTOMOTIVE34175
Newtek Automotive USA34175
POWERSTOPEBR640EVC
PROMAX14-34175
PRONTOBR34175
QUALIS34175
QUINTON HAZELLBDC5232
TRW4196
UAP34175
VAICOV3040043
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51451
WABCOPS126239
WABCO - ArchivedPS126239
WAGNERBD126239E, BD126239
WAGNER BRAKEBD126239
WINHERE661438
Wagner BrakeBD126239E

RAYBESTOS 96940 Fits Vehicles

  • Mercedes-Benz ML55 AMG (2000-2003)
  • Mercedes-Benz ML500 (2002-2005)
  • Mercedes-Benz ML430 (2000-2001)
