CENTRIC 125.35043 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.35043 Specifications
Product Attributes
| Weight [cntrc] Lbs | 18.230 |
| Disc Mounting [cntrc] | Floating / DIH |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 8.290 |
| Misc Holes [cntrc] | 1 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 12.300 MM |
| Discard Thickness | 0.484 IN |
| Nominal Thickness | 13.900 MM |
| Nominal Thickness | 0.547 IN |
| Hat Finish | Painted |
| Overall Height | 55.200 MM |
| Overall Height | 2.173 IN |
| Outside Diameter | 331.500 MM |
| Outside Diameter | 13.051 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 184.100 MM |
| Nominal Drum Diameter | 7.248 IN |
| Bearings Included | No |
| Center Hole Diameter | 67.000 MM |
| Center Hole Diameter | 2.638 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.300 MM |
| Stud/Lug Hole Diameter | 0.602 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890263821 |
CENTRIC 125.35043 Cross References
| Brand | Part Number |
|---|---|
| ATE BRAKE PRODUCTS | 414111, SP14111 |
| N/A | BD126239, E125-40-048, E130-40-048, 414111, 34175, 25528, 34175G, A1634230012, A1634230212, 1634230212, 1634230012, 145331, 96940P, 86940, DDF1099, EBR640, 90063125, E12540048 |
| RAYBESTOS | 96940, 96940R |
| Raybestos Brakes | 96940R, 96940 |
| WAGNER | BD126239 |
CENTRIC 125.35043 Fits Vehicles
- Mercedes-Benz ML55 AMG (2000-2003)
- Mercedes-Benz ML430 (2000-2001)
- Mercedes-Benz ML500 (2002-2005)
