RAYBESTOS 96802 Raybestos Specialty - Street Performance Brake Rotor

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 96802 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2000-1996 BMW 528i Rear, 2003-2001 BMW 530i Rear, 2003-2001 BMW 525i Rear, 2003-1997 BMW 540i Rear

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 96802 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.953 IN
Center Hole Diameter 75 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 0.724 IN
Discard Thickness 18.4 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.724 IN
Mounting Bolt Hole Circle Diameter 120 MM
Mounting Bolt Hole Diameter 0.575 IN
Mounting Bolt Hole Diameter 14.6 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.787 IN
Nominal Thickness 20 MM
Outside Diameter 11.732 IN
Outside Diameter 298 MM
Overall Height 2.402 IN
Overall Height 61 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) DE
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00753497986509

RAYBESTOS 96802 Cross References

BrandPart Number
753497986509, 120.34046
ADVANCE AUTO PARTS145372, YH145372, YH145372C
ALTROM IMPORTS34211164840
AMERICAN REMANUFACTURED89-62047
ATE BRAKE PRODUCTSSP20154, 420154
AUTOXTRA125520, AX34162
AUTOZONE34162DG
AutoZone34162
BECK/ARNLEY083-2707
BENDIX145372
BMW34216767060, 34211163153, 34211164175, 34211164840, 3421164840
BRAKEBEST15010065, 96802, 96802FZN, 96802R, 96802RGS, BD125520
BREMBO09.6841.11, 25446
Brembo09.6841.1X, 09.6841.75
CALIFORNIA DRUM & ROTOR125520
CENTRIC120.34046, 121.34046, 125.34046, 125.34046CRY, 126.34046CSL, 126.34046CSR, 126.34046SL, 126.34046SR, 127.34046CL, 127.34046CR, 127.34046L, 127.34046R, 128.34046CL, 128.34046CR, 128.34046L, 128.34046R, 320.34046, 320.34046H
CONTINENTAL-CONTITECHCW20154
Casting Numbers211238-C, 325910
Centric Parts120.34046, 121.34046, 125.34046, 125.34046CRY, 126.34046CSL, 126.34046CSR, 126.34046SL, 126.34046SR, 127.34046CL, 127.34046CR, 127.34046L, 127.34046R, 128.34046CL, 128.34046CR, 128.34046L, 128.34046R, 320.34046, 320.34046H
DURA CORPBR34162
DuraGoBR34162
EUROROTORBM741
MAGMA PRODUCTSPSR123047
MIGHTY DISTRIBUTING SYSTEM34162
MONROE BRAKESBD125520
NAPA BRAKESSDK6921
NEOTEK106688GF
NEWTEK AUTOMOTIVE34131, 34162
Newtek Automotive USA34131, 34162
PAGID355104612
PAGID Racing355104612
PILENGAV123
POWERSTOPEBR497EVC
PROMAX14-34131, 14-34162
PRONTOBR34162
QUALIS34162
QUINTON HAZELLBDC4677
TRW2783, DF2783S
UAP34162
VAICOV2080027
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51445
WABCOPS125520
WABCO - ArchivedPS125520
WAGNERBD126580, BD125520E
WAGNER BRAKEBD125520
WINHERE442497
WORLDPAC1407-78323
Wagner BrakeBD125520E

RAYBESTOS 96802 Fits Vehicles

  • BMW 540i (1997-2003)
  • BMW 530i (2001-2003)
  • BMW 528i (1996-2000)
  • BMW 525i (2001-2003)
