(888) 312-8812 Login SignupCENTRIC 125.34046 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 4 more
MSRP: $83.46
$3749
Save $45.97
Limited availability at this price!
In Stock
Get it by Thursday, Mar 19
CENTRIC 125.34046 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.34046 Specifications
Product Attributes
| Weight [cntrc] Kgs | 6.180 |
| Disc Mounting [cntrc] | Floating / DIH |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 13.600 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Discard Thickness | 18.400 MM |
| Discard Thickness | 0.724 IN |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Hat Finish | Painted |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 298.000 MM |
| Outside Diameter | 11.732 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 185.000 MM |
| Nominal Drum Diameter | 7.283 IN |
| Bearings Included | No |
| Center Hole Diameter | 75.000 MM |
| Center Hole Diameter | 2.953 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.575 IN |
| Stud/Lug Hole Diameter | 14.600 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890204206 |
CENTRIC 125.34046 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD125520, BD125520E, BD180109, 420154, 6412450, 34162, 34131, 34162G, 34211163153, 34211164175, 34211164840, 34216767060, 145372, 86801, EBR497, 125.34046, 1.0638.6.4, YH145372, 1407-52323, 25446, 96802P, DDF836, DF2783, 19850, 8962047, 142098, 90031044, 150.1286.00 |
| RAYBESTOS | 96802, 96802R |
| Raybestos Brakes | 96802R, 96802 |
| WAGNER | BD126580, BD125520 |
CENTRIC 125.34046 Fits Vehicles
- BMW 540i (1997-2003)
- BMW 530i (2001-2003)
- BMW 525i (2001-2003)
- BMW 528i (1996-2000)
