(888) 312-8812 Login SignupRAYBESTOS 980157R Raybestos R-Line Brake Rotor
$7699
Limited availability at this price!
In Stock
Get it by Monday, Mar 9
RAYBESTOS 980157R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2006-2003 Dodge Sprinter 2500 Front, 2006-2004,2002 Freightliner Sprinter 2500 Front, 2005-2002 Freightliner Sprinter 3500 Front, 2005-2003 Dodge Sprinter 3500 Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980157R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.347 IN |
| Center Hole Diameter | 85 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
| Mounting Bolt Hole Diameter | 15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 10.855 IN |
| Outside Diameter | 275.7 MM |
| Overall Height | 3.03 IN |
| Overall Height | 76.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352467541 |
RAYBESTOS 980157R Cross References
| Brand | Part Number |
|---|---|
| ASH12326, 829352467541 | |
| ADVANCE AUTO PARTS | YH145424, YH145424C |
| AUTOXTRA | AX34225 |
| AUTOZONE | 34225, 34225DG |
| BENDIX | 145424 |
| BRAKEBEST | 980157, 980157R, 980157RGS, BD126307 |
| BREMBO | 09.9618.14 |
| CENTRIC | 120.35072, 121.35072, 125.35072, 126.35072SL, 126.35072SR, 127.35072L, 127.35072R |
| CHRYSLER | 05104561AA, 05104561AB, 5104561AA, 5104561AB, 5104562AA, 9024210612 |
| Casting Numbers | 325993 |
| Centric Parts | 120.35072, 121.35072, 125.35072, 126.35072SL, 126.35072SR, 127.35072L, 127.35072R |
| DURA CORP | BR34225 |
| DuraGo | BR34225 |
| FREIGHTLINER CUSTOM CHASSIS | 9024210612 |
| MIGHTY DISTRIBUTING SYSTEM | 34225 |
| NEWTEK AUTOMOTIVE | 34225 |
| Newtek Automotive USA | 34225 |
| PROMAX | 14-34225 |
| QUALIS | 34225 |
| QUINTON HAZELL | BDC4544 |
| TRW | 2790 |
| UAP | 34225 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51626 |
| WABCO | PS126307 |
| WABCO - Archived | PS126307 |
| WAGNER | BD126357, BD126307E |
| WAGNER BRAKE | BD126307 |
| WINHERE | 662539 |
| Wagner Brake | BD126307E |
RAYBESTOS 980157R Fits Vehicles
- Freightliner Sprinter 2500 (2002-2006)
- Freightliner Sprinter 3500 (2002-2006)
- Mercedes-Benz Sprinter (2007-2012)
- Dodge Sprinter 2500 (2003-2006)
- Dodge Sprinter 3500 (2003-2006)
