CENTRIC 120.47028 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.47028 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 3 |
| Max Pb Drum Dia [cntrc] Mm | 211.000 |
| Max Pb Drum Dia [cntrc] In | 8.307 |
| Weight [cntrc] Kgs | 7.140 |
| Weight [cntrc] Lbs | 15.700 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Hat Finish | Painted |
| Overall Height | 67.700 MM |
| Overall Height | 2.665 IN |
| Outside Diameter | 319.700 MM |
| Outside Diameter | 12.587 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 210.000 MM |
| Nominal Drum Diameter | 8.268 IN |
| Bearings Included | No |
| Center Hole Diameter | 58.000 MM |
| Center Hole Diameter | 2.283 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.512 IN |
| Stud/Lug Hole Diameter | 13.000 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890228547 |
CENTRIC 120.47028 Cross References
| Brand | Part Number |
|---|---|
| 980378, BD126495 | |
| N/A | BD126495, 0833341, E125-52-033, 44571, YH145794, 44571G, 26700XA00A, 880378, 31415, 90013036, E12552033 |
| NEOTEK | 106410GF |
| Neotek Premium Drums and Rotors | 106410GF |
| RAYBESTOS | 980378, 980378FZN, 980378R, 980378R2 |
| Raybestos Brakes | 980378, 980378FZN, 980378R |
| WAGNER | BD126495E, BD126495 |
CENTRIC 120.47028 Fits Vehicles
- Subaru B9 Tribeca (2006-2007)
- Subaru Tribeca (2008-2014)
