(888) 312-8812 Login SignupMONROE 33201 Monro-Matic Plus Suspension Shock Absorber
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MONROE 33201 Part Description
Manufacturer
Product Description
Monro-Matic Plus Suspension Shock Absorber
Features & Benefits
- CONSISTENT RIDE -- Velocity Proportional Valving (VPV) technology and all-weather fluid containing special additives to reduce friction and ensure smooth rod reaction and an overall smoother ride
- RELIABLE PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- RESTORES RIDE AND HANDLING -- Larger bore provides more efficient damping control to provide consistency and a smooth ride (where applicable)
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while banded piston and bronze reinforced guide provide durability
- GET MORE MILES FROM YOUR RIDE -- Designed and validated to meet OE spec and deliver consistent performance
MONROE 33201 Specifications
Product Attributes
| Lower Mount Code | LS50 |
| Upper Mount Code | LS50 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.75 IN |
| Compressed Length | 11.69 IN |
| Dust Shield Material | Metal |
| Extended Length | 17 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 16MM Sleeve X 1.55" Sleeve OAL |
| Parts Pack(s) | None |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Travel Length | 5.32 in |
| Upper Mount Type | Loop with bushing and sleeve |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 16MM Sleeve X 1.55" Sleeve OAL |
| Compressed Length | 296.9 MM |
| Extended Length | 431.8 MM |
| Travel Length | 135.1 MM |
| Body Diameter | 44.4 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS50 |
| Upper Mount Code | LS50 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| UPC | 00048598238603 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 33201 Cross References
| Brand | Part Number |
|---|---|
| FCS | 342875 |
| FCS Auto Parts | 342875 |
| Gabriel | G64144 |
| KYB | 349217, 551140, 3440028 |
| Kia | 553101U600, 553101U000, 553101U200, 553101U300, 553101U400, 553101U500 |
| NAPA Response | 94346 |
MONROE 33201 Fits Vehicles
- Kia Sorento (2011-2013)
- Hyundai Veracruz (2007-2012)
- Hyundai Santa Fe (2007-2012)
