(888) 312-8812 Login SignupMOTORAD 2IC277 Ignition Coil
Tap to view 6 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MOTORAD 2IC277 Part Description
Manufacturer
Product Description
Ignition Coil
Features & Benefits
- Primary and secondary windings made with ETP grade copper to provide superior temperature protection and voltage conductivity.
- Graphite-infused platinum connections resist corrosion and offer superior conductivity and durability.
- Heat resistant magnet produces max voltage output at all engine speeds.
- Preapplied dielectric grease for easy installation.
MOTORAD 2IC277 Specifications
Product Attributes
| Mounting Bracket Included | No |
| Product Color | Black, White |
| Grade Type | Regular |
| Terminal Quantity | 3 |
| Requires External Resistor | Yes |
| Terminal Gender | Male |
| Voltage | 12 VDC |
| Terminal Type | Blade |
| Primary Resistance | 400-1200 Ohms |
| Connector Quantity | 1 |
| Secondary Resistance | 11500-17500 Ohms |
| Connector Gender | Male |
| Oil Filled | No |
| Hazardous Material | No |
| Oe Replacement | YES |
| Quantity Per Application | 1 |
| Terminal Type | Blade |
| Terminal Quantity | 3 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Mounting Bracket Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | TX |
| UPC | 00055644688862 |
MOTORAD 2IC277 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | F513, E520A |
| Ford | E8GY12029A, E8GY12029B, E92Z12029B, F02Z12029A, F02Z12029B, E7GY12029A, FO2Z12029B, FO2Z12029C |
| General Motors | 89057146, 19017123, 19017124, 88921252 |
| Mazda | JE571810XA, JF0118100B, JF011810X, JF031810XB, JF071810X, F21018100, F21018100A, F21118100, F21118100A, F2201810XE, F2851810X, F2851810XA, F2851X810, F2851X810A, F2861810X, F2861810XA, F2F61X810, JE151810X, JE161810X, JE1618X10, JE261810XA, JE571810X, E5D318100B, E5D718100A, E5D718100B |
| Mighty Distributing System | 6514, 6530 |
| Motorad | 2IC277 |
| Motorcraft | DGE432, DGE437, DGE439, DGE442, DGE443 |
| STANDARD IGNITION | UF-22 |
| Suzuki | 3341064B10 |
MOTORAD 2IC277 Fits Vehicles
- Mazda MPV (1989-1995)
- Mazda 323 (1986-1989)
- Mazda 626 (1988-1992)
- Mazda 929 (1988-1991)
- Mazda MX-6 (1988-1992)
- Mercury Tracer (1987-1989)
- Mercury Capri (1991-1994)
- Ford Probe (1989-1992)
- Suzuki Swift (1989-1994)
