MOTORAD 3IC196 Part Description
Manufacturer
Product Description
Ignition Coil
Features & Benefits
- Primary and secondary windings made with ETP grade copper to provide superior temperature protection and voltage conductivity.
- Graphite-infused platinum connections resist corrosion and offer superior conductivity and durability.
- Heat resistant magnet produces max voltage output at all engine speeds.
- Preapplied dielectric grease for easy installation.
MOTORAD 3IC196 Specifications
Product Attributes
| Terminal Gender | Male |
| Product Color | Black, White |
| Requires External Resistor | Yes |
| Grade Type | Regular |
| Connector Gender | Male |
| Terminal Type | Threaded |
| Primary Resistance | 1100-1700 Ohms |
| Voltage | 12 VDC |
| Quantity Per Application | 1 |
| Hazardous Material | No |
| Oe Replacement | YES |
| Secondary Resistance | 10000-15000 Ohms |
| Oil Filled | No |
| Mounting Bracket Included | No |
| Terminal Quantity | 2 |
| Terminal Type | Threaded |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 4 |
| Terminal Quantity | 2 |
| Connector Gender | Male |
| Terminal Gender | Male |
| Mounting Bracket Included | No |
Additional Information
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | TX |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Country of Origin (Primary) | CN |
| UPC | 00055644688633 |
MOTORAD 3IC196 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | E596 |
| General Motors | 88921431, 94404545, 94853695 |
| Isuzu | 8944045450 |
| Motorad | 3IC196 |
| Opel | 94404545, 94853695 |
| STANDARD IGNITION | UF-103 |
| Toyota | 9091902164 |
MOTORAD 3IC196 Fits Vehicles
- Pontiac Sunburst (1985-1988)
- Toyota Tercel (1987)
- Toyota Corolla (1986-1989, 1993-1995)
- Toyota Celica (1994-1995)
- Geo Spectrum (1989)
- Geo Prizm (1993-1995)
- Chevrolet Spectrum (1986-1988)
- Isuzu I-Mark (1985-1989)
