ATE BRAKE PRODUCTS 428154 Part Description
Manufacturer
Product Description
ATE Original Front Disc Brake Rotor 428154 for Land Rover, Volvo
Features & Benefits
- Application specific design is engineered to tighter tolerances
- Protective coating ensures long lasting corrosion resistance
- High carbon brake disc optimize durability and prevents brake judder and noise
- Use of state of the art original replacement part materials in the production of the rotors
ATE BRAKE PRODUCTS 428154 Specifications
Product Attributes
| Outside Diameter | 300.00 MM |
| Inside Diameter | 140.00 MM |
| Nominal Thickness | 28.00 MM |
| Discard Thickness | 26.00 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Overall Height | 52.00 MM |
| Material | High-carbon |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Stud/Lug Hole Circle Diameter | 108.00 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.80 MM |
| Center Hole Diameter | 63.50 MM |
| Directional or Non-Directional Brake Surface | Non-Directional |
Additional Information
| Country of Origin (Primary) | IT |
| EU | |
| UPC | 04006633309851 |
ATE BRAKE PRODUCTS 428154 Cross References
| Brand | Part Number |
|---|---|
| Bendix | 562363B |
| Bosch | 0 986 479 261, 0 986 479 974 |
| Brembo | 09.A427.10, 09.A427.11, 09.A427.1X |
| Delphi | BG4094 |
| Febi-Bilstein | 28361 |
| Ferodo America | DDF1567, DDF1567-1, DDF1567C |
| Hella | 54592, 54969, 8DD 355 113-821, 8DD 355 118-831 |
| Land Rover | LR000571, LR007055 |
| N/A | LR000571 |
| Qualis | 45458 |
| Raybestos Brakes | 980725 |
| TRW | DF4850S |
| Textar | 92159200, 92159203, 92196900, 92196903, 98200 1592 0 1, 98200 1969 0 1 |
| Valeo | 197055 |
| Volvo | 30769056, 307690560, 31202331, 312023310, 31341382, 313413820, 31358885, 313588850 |
| Wagner Brake | BD180354 |
| Zimmermann | 250.1360.20, 250.1360.52, 250136020 |
ATE BRAKE PRODUCTS 428154 Fits Vehicles
- Volvo V60 (2015-2018)
- Volvo S60 (2011-2018)
- Volvo V70 (2008-2010)
- Volvo XC70 (2008-2016)
- Volvo S80 (2007-2016)
- Land Rover Range Rover Evoque (2012-2015)
