(888) 312-8812 Login SignupNGK SPARK PLUGS U2103 NGK DIS Ignition Coil
Tap to view 2 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS U2103 Part Description
Manufacturer
Product Description
NGK DIS Ignition Coil
Features & Benefits
- OE QUALITY: Vacuum-sealed premium epoxy resin and thermoplastic coil housings provide superior dielectric strength, voltage insulation and durability
- OPTIMAL PERFORMANCE: Precision coil windings and laminations maximize outputs, custom NGK ASIC chipset optimizes efficiency, prevents component damage
- EASE OF INSTALLATION: Includes mounting hardware and necessary components required for certain applications to ensure worry-free installation
- THE NGK DIFFERENCE: Featuring superior materials and design enhancements, NGK's problem solving solutions are backed by a 3 year/36,000 mile warranty
- EXTENSIVE TESTING: NGK ignition coils must pass extreme testing during manufacturing to ensure the highest quality and durability standards are met
- PRODUCT ENGINEERING: Advanced flow and stress modeling systems preemptively identify and avoid common failure points found in OE and competitor coils
NGK SPARK PLUGS U2103 Specifications
Product Attributes
| Connector Quantity | 1 |
| Part Number | U2103 |
| Stock Number | 49078 |
| Color | Black |
| Voltage | 12.0 2H |
| Ignition Type | Distributorless |
| Coil Type | DIS |
| Oil Filled | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Grade Type | Standard Replacement |
| Terminal Quantity | 3 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Mounting Bracket Included | No |
| Mount Type | Bolt-On |
| Mounting Hole Quantity | 4 |
Additional Information
| Warranty Distance | 36000 |
| Warranty Time UOM | MO |
| Warranty Time | 36 |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8511300080 |
| Warranty Distance UOM | DH |
| UPC | 00087295490785 |
| UNSPSC | 26101769 |
NGK SPARK PLUGS U2103 Cross References
| Brand | Part Number |
|---|---|
| Altrom Group | 1415086, 1415118 |
| Autopart International | 2505-77099 |
| BWD | E238, E251P, E251 |
| Beck/Arnley | 178-8404, 178-8308 |
| DENSO | 673-6006, 673-6009 |
| DENSO Auto Parts | 673-6006, 673-6009 |
| Delphi | GN10185, GN10129 |
| Echlin | IC362, IC379 |
| Ford | XS8Z-12029-AA, XS8Z-12029-AD, YS8Z-12029-AA, 1S7Z-12029-AA, 1S7Z-12029-AD, 988F-12029-AB, 988F-12029-AC, 988F-12029-AD, 988Z-12029-A |
| HOLSTEIN | 2IGC0049 |
| Mazda | LF01-18-100A, YF09-18-10X, YFTT-18-10X, ZZC0-18-10X, 1F20-18-100, 1F20-18-100A, LF01-18-100 |
| Motorcraft | DG536, DG474, DG506, DG544, DG489 |
| N/A | 1S7G-12029-AD, 1F2018100A, U2103, IGC0112, C1341, 1S7G12029AD, 1F2018100, C1341VC, 23-0187, 988F12029AD, 988F12029AE, 988Z12029A, YS8Z12029AA, 1S7Z12029AA, 988F12029AC, 1S7Z12029AD, 988F12029AB, 988F-12029-AE, XS8Z12029AA, XS8Z12029AD, ZZC01810X, LF0118100, YF091810X, LF0118100A, YFTT1810X |
| NAPA Mileage Plus | IC379SB, IC362SB |
| NGK | 49078 |
| PRENCO | 36-1171 |
| SPECTRA PREMIUM | C-501 |
| STANDARD IGNITION | FD497 |
| Standard Import | FD501 |
| Standard Motor Products | FD497, FD-497, FD-501 |
| T Series | FD497T, FD501T |
NGK SPARK PLUGS U2103 Fits Vehicles
- Mazda B2300 (2001-2010)
- Mazda 6 (2003-2005)
- Mazda Tribute (2001-2004)
- Mercury Mystique (1999-2000)
- Ford Contour (1999-2000)
- Ford Ranger (2001-2011)
- Ford Focus (2000-2004)
- Ford Escape (2001-2004)
