(888) 312-8812 Login SignupRAYBESTOS 980479R Raybestos R-Line Brake Rotor
$5549
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Mar 20
RAYBESTOS 980479R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2000-1999 Volvo S70 Rear, 2000-1999 Volvo V70 Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980479R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.25 IN |
| Mounting Bolt Hole Circle Diameter | 107.95 MM |
| Mounting Bolt Hole Diameter | 0.625 IN |
| Mounting Bolt Hole Diameter | 15.9 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.339 IN |
| Outside Diameter | 288 MM |
| Overall Height | 2.437 IN |
| Overall Height | 61.9 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213372311 |
RAYBESTOS 980479R Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 200888, 832814, YH145148, YH200888 |
| Bosch | 52011356 |
| BrakeBest | 52011356, 980479, 980479RGS |
| Brembo | 08.A600.10 |
| CENTRIC | 121.39030 |
| Centric Parts | 120.39030, 121.39030, 125.39030, 126.39030CSL, 126.39030CSR, 126.39030SL, 126.39030SR, 127.39030CL, 127.39030CR, 127.39030L, 127.39030R |
| Dura Corp | BR34309 |
| DuraGo | BR34309 |
| MAGMA PRODUCTS | PMR603026 |
| Newtek Automotive USA | 34309 |
| Promax | 14-34309 |
| Qualis | 45417 |
| TRW | 6048 |
| UAP | 34309 |
| Volvo | 272429, 2724292, 31262097 |
| Wagner Brake | BD125743 |
| Winhere | 441555 |
RAYBESTOS 980479R Fits Vehicles
- Volvo V70 (1999-2000)
- Volvo S70 (1999-2000)
