(888) 312-8812 Login SignupFREIGHTLINER A16-21709-000 Air Bag - A/L, CO, CP, 36/65/323, 25, Neoprene, Steel, M12X1.5 mm
Tap to view 4 more
SHIPS TODAY
$62099
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
FREIGHTLINER A16-21709-000 Part Description
Manufacturer
Product Description
Air Bag - A/L, Co, Cp, 36/65/323, 25
Features & Benefits
- Stringently evaluated to ensure reliable performance
- Installation process is very straightforward
- Manufactured with premium material for practical and long-term use
- Designed to meet or exceed OEM specifications
Freightliner Air Suspension Spring
For maximum air suspension performance, be sure to get a high-quality Freightliner air suspension spring as a replacement. Freightliner offers a large selection of top-quality, direct replacement parts, all designed to make air suspension repair and maintenance a breeze.
FREIGHTLINER A16-21709-000 Specifications
Product Attributes
| Bellows Material | Neoprene |
| Piston Material | Plastic |
| Bracket Material | Steel |
| Height | 310 mm |
| Hole Thread Size | M12 x 1.5 mm |
| Maximum Diameter | 320 mm |
| Mounting Stud Thread Size | 1/2-13 UNC 2A in. |
| Operating Pressure | 100 psi |
| Piston Diameter | 260 mm |
| Plate Diameter | 227 mm |
| Plate Material | Steel |
| Maximum Height | 12.2 in |
| Maximum Operating Pressure | 100 psi |
| Maximum Load Capacity | 7524.35 lbs |
| Mounting Stud Quantity | 1 |
| Mount Hole Center To Center Length | 5.78 in |
| Mounting Hole Thread Size | M12X1.5 mm |
| OEM Part Number | A1621709000, A16 21709 000, A16-21709-000 |
| OEM Description | AIR BAG - A/L, CO, CP, 36/65/323, 25 |
| Inlet Thread Size | M12X1.5 mm |
| Top Plate Diameter | 8.93 in |
| Minimum Height | 8 in |
| VMRS | 016-008-001 |
| Bellows Material | Neoprene |
| Minimum Operating Pressure | 5 psi |
| Piston Material | Plastic |
| Maximum Outer Diameter | 12.6 in |
FREIGHTLINER A16-21709-000 Manufacturer Information
Freightliner® is the best-selling brand of heavy duty trucks in North America. But when it's time to service any of these trucks, it also provides customers with the parts they need right when and where they need them. Its distribution centers are located across the United States and utilize only the latest product-sourcing technology to ensure quick and hassle-free delivery of parts. Freightliner knows how crucial these trucks are for your business operations, so it provides you with only the highest-quality replacement parts to keep your vehicles back on the road. With genuine parts from this brand, customers would never have to worry about installation and performance at all.
