(888) 312-8812 Login SignupCENTRIC 320.35106H Centric GCX Rotor with Full Coating and High Carbon Content
Tap to view 4 more
$7849
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Mar 6
CENTRIC 320.35106H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.35106H Specifications
Product Attributes
| Weight [cntrc] Kgs | 9.180 |
| Weight [cntrc] Lbs | 20.200 |
| Vane Style [cntrc] | Pillar |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] In | 6.043 |
| Hat Id [cntrc] Mm | 153.500 |
| Misc Holes [cntrc] | 1 |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25.000 MM |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 68.400 MM |
| Overall Height | 2.693 IN |
| Outside Diameter | 299.700 MM |
| Outside Diameter | 11.799 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.346 IN |
| Center Hole Diameter | 85.000 MM |
| Mounting Bolt Hole Circle Diameter | 130.200 MM |
| Mounting Bolt Hole Circle Diameter | 5.126 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 15.300 MM |
| Stud/Lug Hole Diameter | 0.602 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590388152 |
CENTRIC 320.35106H Cross References
CENTRIC 320.35106H Fits Vehicles
- Freightliner Sprinter 2500 (2007-2020)
- Freightliner Sprinter 3500 (2007-2018)
- Mercedes-Benz Sprinter 3500XD (2018-2023)
- Mercedes-Benz Sprinter 4500 (2019-2023)
- Mercedes-Benz Sprinter 1500 (2019-2023)
- Volkswagen Crafter Van (2008-2017)
- Dodge Sprinter 3500 (2007-2009)
- Dodge Sprinter 2500 (2007-2009)
- Mercedes-Benz Sprinter 3500 (2010-2023)
- Mercedes-Benz Sprinter 2500 (2010-2023)
