(888) 312-8812 Login SignupDELPHI TC5732 Ball Joint
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI TC5732 Part Description
DELPHI TC5732 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Material | Steel |
| Maximum Outside Diameter | 1.555 IN |
| Maximum Outside Diameter | 39.5 MM |
| Color | Gray |
| Stud Thread Diameter | 12.0 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 39.5 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 3.346 IN |
| Nuts Included | Yes |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.748 IN |
| Stud Type | Threaded |
| Mounting Type | Press In |
| Dust Boot Material | Choloroprene Rubber (CR) |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| Stud Tapered End 2 Diameter | 0.531 IN |
| Stud Tapered End 2 Diameter | 13.5 MM |
| Stud Tapered End 1 Diameter | 0.657 IN |
| Stud Tapered End 1 Diameter | 16.7 MM |
| Stud Thread Pitch | 1.25 MM |
| Length | 85.0 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Country of Origin (Primary) | TR |
| UPC | 00689604311622 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC5732 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-7695, 101-7697, 101-7716, 102-5418, 102-5419 |
| DORMAN | B90310, B90310XL |
| Dorman | 520-431, 520-432, 522-297, 522-298 |
| MAS Industries | CB74013, CB74013PR, CB74014, CB74014PR, CB74023, CB74023PR, CB74024, CB74024PR |
| MEVOTECH | MK90310 |
| MOOG Chassis Products | RK620364, RK620365, 101-7695, 101-7697, 101-7716, 102-5418, 102-5419 |
| Toyota | 48068-59055, 48069-59055 |
DELPHI TC5732 Fits Vehicles
- Toyota Echo (2003-2005)
