(888) 312-8812 Login SignupICON 56505 / 4 RUNNER 1-3' RR 2.0 VS
$28749
Limited availability at this price!
In Stock
Get it by Tuesday, Mar 3
ICON 56505 Part Description
Manufacturer
Product Description
07-14 FJ/03-24 4RNR/03-23 GX 1-3" REAR 2.0 VS IR
Features & Benefits
- Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
- Nitrogen charged monotube design with internal reservoir
- One piece linear/digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- 5/8” chrome plated hardened steel shaft resists corrosion and pits
- 6061 aluminum rod end, top cap, and internals ensure strength and durability
- Polyurethane bushings, zinc plated sleeves, and forged steel mounting stems for OE factory type fitment
- 6063 anodized aluminum body and reservoir tubing for superb heat dissipation, excellent corrosion resistance, and high-tech appearance
- Nitrile rubber top out bumper for noise free operation
- 100% rebuildable
- 100% revalveable
TECH NOTE: Compatible with 1-3" of rear lift over stock
ICON 56505 Specifications
Product Attributes
| Aap_uda_12 | EA |
| Aap_uda_22 | 1 |
| Aap_uda_4 | 55 |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Body Color | Gray |
| Body Diameter | 2 IN |
| Body Material | Aluminum |
| Boot Included | Yes |
| Bore Diameter | 1.75 IN |
| Bushing Color | Black |
| Bushing Included | yes |
| Bushing Material | Rubber |
| California Prop 65 Warning | Yes |
| Coil Over Springs Included | NO |
| Coil Spring Insulator(s) Included | No |
| Color | Silver |
| Configuration | One Piece |
| Cylinder Color | Gray |
| Cylinder Finish | Anodized |
| Cylinder Material | Aluminum |
| Cylinder Outside Diameter | 2 IN |
| Damping Type | Oil |
| Dust Boot Included | Yes |
| Dust Shield | Yes |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| External Reservoir | No |
| Finish | Anodized |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Single Tube |
| Internal Rebound Bumper | Yes |
| Internal Rebound Spring | No |
| Lower Mount Type | EYELET |
| Material | Steel |
| Maximum Ride Height Raising Distance | 3 IN |
| Mounting Hardware Included | Yes |
| Quantity | 1 |
| Remote Reservoir | NO |
| Rod Diameter | .625 IN |
| Self-Leveling | No |
| Service Parts | 252004 - ECONOMY NEEDLE CHARGING TOOL |
| Shaft Diameter | 0.625 IN |
| Shaft Material | Chrome |
| Shock Absorber Body End Measuring Point | Shoulder of Stem |
| Shock Absorber Bore Size | 1.75 IN |
| Shock Absorber Rod End Measuring Point | Center of Eylet |
| Suspension Type | Spring |
| Title | ICON 2007-2014 Toyota FJ Cruiser/2003-2024 Toyota 4Runner/2003-2023 Lexus GX, 1-3” Lift, Rear, 2.0 Aluminum Series Shock Absorber, Internal Reservoir |
| Upper Mount Type | Stem |
| Valving Type | Linear |
Additional Information
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| NAFTA Preference Criterion Code | C |
| UPC | 00840103403076 |
ICON 56505 Fits Vehicles
- Toyota FJ Cruiser (2007-2014)
- Toyota 4Runner (2003-2024)
- Lexus GX460 (2010-2023)
- Lexus GX470 (2003-2009)
