RAYBESTOS 982271 Raybestos Specialty - Street Performance Coated Brake Rotor

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 982271 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Coated Brake Rotor

Application Summary

2016-2011 BMW 535i xDrive Front, 2016-2011 BMW 535i Front, 2018-2012 BMW 640i Front, 2016-2014 BMW 535d xDrive Front, 2016-2014 BMW 535d Front, 2019-2013 BMW 640i Gran Coupe Front, 2019-2014 BMW 640i xDrive Gran Coupe Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 982271 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.953 IN
Center Hole Diameter 75 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.118 IN
Discard Thickness 28.4 MM
Harmonize Code 8708.30.5030
Inside Diameter 8.484 IN
Inside Diameter 215.5 MM
Mounting Bolt Hole Circle Diameter 4.724 IN
Mounting Bolt Hole Circle Diameter 120 MM
Mounting Bolt Hole Diameter 0.654 IN
Mounting Bolt Hole Diameter 16.6 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.181 IN
Nominal Thickness 30 MM
Outside Diameter 13.701 IN
Outside Diameter 348 MM
Overall Height 2.602 IN
Overall Height 66.1 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Diameter 0.654 IN
Stud/Lug Hole Diameter 16.6 MM
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213306927

RAYBESTOS 982271 Cross References

RAYBESTOS 982271 Fits Vehicles

  • BMW 535d xDrive (2014-2016)
  • BMW 535d (2014-2016)
  • BMW 640i xDrive Gran Coupe (2014-2019)
  • BMW 640i xDrive (2014-2018)
  • BMW ActiveHybrid 5 (2012-2016)
  • BMW 640i Gran Coupe (2013-2019)
  • BMW 640i (2012-2018)
  • BMW 535i xDrive (2011-2016)
  • BMW 535i (2011-2016)
