DELPHI TC5087 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC5087 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 3.504 IN |
| Maximum Outside Diameter | 89.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.472 IN |
| Stud Thread Diameter | 12 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 84.5 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 2.224 IN |
| Mounting Bolt Length | 56.50 MM |
| Washers Included | No |
| Height | 4.213 IN |
| Height | 107.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.76 IN |
| Stud Thread Length | 19.3 MM |
| Wrench Size | 19mm |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 55.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 0.394 IN |
| Mounting Bolt Shank Diameter | 10.00 MM |
| Mounting Bolt Head Diameter | 0.720 IN |
| Mounting Bolt Head Diameter | 18.30 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.5 MM |
| Mounting Bolt Thread Length | 1.181 IN |
| Mounting Bolt Thread Length | 30.00 MM |
| Mounting Bolt Thread Diameter | 10.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.65 IN |
| Stud Tapered End 2 Diameter | 16.5 MM |
| Stud Tapered End 1 Diameter | 0.571 IN |
| Stud Tapered End 1 Diameter | 14.5 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 89.00 MM |
| Length | 3.500 IN |
| Mounting Bolt Thread Diameter | 0.390 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604284391 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC5087 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-3393 |
| DORMAN | BJ43245, BJ43245PR |
| MEVOTECH | MS70507 |
| MOOG | K9029 |
| MOOG Chassis Products | ES419L, K9029 |
| N/A | BJ43245PR, 536654, BJ43245, 101-3380, 113-407-361E, 113407361F, MS70507 |
| Volkswagen | 113407361C, 113415811C |
DELPHI TC5087 Fits Vehicles
- Volkswagen Super Beetle (1971-1973)
