RAYBESTOS 680998FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2019-2013 Ford Escape Front, 2014-2013 Ford Focus Front, 2018-2014 Ford Transit Connect Front, 2019-2018 Lincoln MKC Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 680998FZN Specifications
Product Attributes
| Center Hole Diameter | 2.5 IN |
| Center Hole Diameter | 63.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.402 IN |
| Inside Diameter | 188 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108 MM |
| Mounting Bolt Hole Diameter | 0.54 IN |
| Mounting Bolt Hole Diameter | 13.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.984 IN |
| Nominal Thickness | 25 MM |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320 MM |
| Overall Height | 1.921 IN |
| Overall Height | 48.8 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213232271 |
RAYBESTOS 680998FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH516223P |
| AUTOPARTSOURCE | 421510 |
| AUTOXTRA | AX901294 |
| AutoZone | 79900, 79900DG, 79900DL |
| BOSCH | 20011521 |
| BRAKEBEST | 20011521, 621691RGS, 680998, 680998FZN, 680998R, 680998RGS |
| Brembo | 09.C542.11, 09.C542.21 |
| CENTRIC | 320.39038, 320.39038C |
| Centric Parts | 120.39038, 121.39038, 125.39038 |
| DURA CORP | BR901294 |
| Dura Corp | BR900990 |
| DuraGo | BR900990, BR901294, BR901294-01, BR901294-02 |
| FORD | 1829608, 1844117, CV6Z1125B, CV6Z1125D, CV611125FA, DV611125BC, DV6Z1125C |
| Ford | KU2Z1V125B |
| NAPA BRAKES | SDK6740 |
| NEWTEK AUTOMOTIVE | 54192, R1294 |
| Newtek Automotive USA | 54192, R1294 |
| POWERSTOP | EBR897EVC |
| Qualis | 42308, 45440 |
| TopNotch | TN680998GEO |
| VOLVO | 31400818, 314008180, 31400938, 314009380 |
| WORLDPAC | 1407-516223, 1427-731977 |
| WORLDPARTS | WS1-154192 |
RAYBESTOS 680998FZN Fits Vehicles
- Volvo V50 (2005-2011)
- Volvo S40 (2004-2012)
- Volvo C70 (2006-2013)
- Lincoln MKC (2018-2019)
- Ford Transit Connect (2014-2018)
- Ford Focus (2013-2018)
- Ford Escape (2013-2019)
