(888) 312-8812 Login SignupRAYBESTOS 96706FZN Raybestos Element3 Coated Brake Rotor
$3349
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Mar 13
RAYBESTOS 96706FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2001-1997 Honda Prelude Rear
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 96706FZN Specifications
Product Attributes
| Center Hole Diameter | 2.524 IN |
| Center Hole Diameter | 64.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.355 IN |
| Nominal Thickness | 9 MM |
| Outside Diameter | 10.225 IN |
| Outside Diameter | 259.7 MM |
| Overall Height | 1.66 IN |
| Overall Height | 42.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213232370 |
RAYBESTOS 96706FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 145159, YH145159, YH145159C, YH145159P |
| AMERICAN REMANUFACTURED | 89-08041 |
| AUTOSPECIALTY | JBR798, JBR798E |
| AUTOXTRA | 125605, AX31227 |
| AUTOZONE | 31227, 31227DG |
| Autoxtra | AX31227P |
| BECK/ARNLEY | 083-2676 |
| BENDIX | 145159 |
| BRAKEBEST | 96706, 96706R, 96706RGS, BD125605 |
| BREMBO | 25177 |
| Brembo | 08.9529.10 |
| CENTRIC | 120.40040CRY |
| CONTINENTAL-CONTITECH | CW09712 |
| Casting Numbers | 211133-C, 325462 |
| Centric Parts | 120.40040, 120.40040CRY, 121.40040, 126.40040CSL, 126.40040CSR, 126.40040SL, 126.40040SR, 127.40040CL, 127.40040CR, 127.40040L, 127.40040R, 128.40040CL, 128.40040CR, 128.40040L, 128.40040R, 227.40040L, 227.40040R, 320.40040, 125.40040, 321.40040 |
| DURA CORP | BR31227, BR3122702 |
| DuraGo | BR31227 |
| EUROROTOR | HO567 |
| GREN | 42801 |
| HONDA | 42510S30A00 |
| MIGHTY DISTRIBUTING SYSTEM | 31227 |
| NEWTEK AUTOMOTIVE | 31227 |
| Newtek Automotive USA | 31227 |
| PEP BOYS | 31227G |
| PROMAX | 14-31227 |
| QUALIS | 31227 |
| QUALITEE INTERNATIONAL | 64-72-400 |
| QUALITY BRAND | 31227, Q132 |
| STANDARD ROTORS AND DRUMS | 31227 |
| THE UNIVERSAL GROUP | 108400 |
| TRUSTAR | 472400, R72400 |
| UAP | 31227 |
| Ultra Brake | HO-567 |
| Universal | 108400 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51268 |
| WABCO | PS125605 |
| WABCO - Archived | PS125605 |
| WAGNER BRAKE | BD125605 |
| WINHERE | 661353, YH1353 |
| Wagner Brake | BD125605E |
RAYBESTOS 96706FZN Fits Vehicles
- Honda Prelude (1997-2001)
