(888) 312-8812 Login SignupRAYBESTOS 981503FZN Raybestos Element3 Coated Brake Rotor
$9549
Limited availability at this price!
In Stock
Get it by Thursday, Feb 26
RAYBESTOS 981503FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2018-2014 Mazda 3 Front, 2022-2016 Mazda CX-3 Front, 2016,2014 Mazda 3 Sport Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 981503FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.693 IN |
| Inside Diameter | 170 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.524 IN |
| Mounting Bolt Hole Diameter | 13.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.984 IN |
| Nominal Thickness | 25 MM |
| Outside Diameter | 11.016 IN |
| Outside Diameter | 279.8 MM |
| Overall Height | 2.028 IN |
| Overall Height | 51.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213236866 |
RAYBESTOS 981503FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH507589P |
| ADVICS | E6F117U |
| AUTOPARTSOURCE | 474741 |
| AUTOXTRA | AX901286 |
| AUTOZONE | 71109, 77109DL |
| AutoZone | 77109DG |
| BENDIX | PRT6259 |
| BRAKEBEST | 34011591, 921659RGS, 981503R, 981503, 981503FZN |
| Brembo | 09.C651.11, 09.C651.1X |
| CENTRIC | 120.45088, 121.45088, 126.45088SL, 126.45088SR, 127.45088L, 127.45088R, 320.45088 |
| Centric Parts | 120.45088, 121.45088, 126.45088SL, 126.45088SR, 127.45088L, 127.45088R, 320.45088 |
| DURA CORP | BR901286 |
| DuraGo | BR901286 |
| Dynamic Friction Company | 604-80053 |
| Eurorotor | MA-8030 |
| MAZDA | BJS733251A, B45A33251A, BPY133251 |
| NEWTEK AUTOMOTIVE | R1286 |
| Newtek Automotive USA | R1286 |
| POWERSTOP | JBR1599EVC |
| PROMAX | 14-610012 |
| Qualis | 44790 |
| TopNotch | TN981503GEO |
| Ultra Brake | MA-8030 |
| WORLDPAC | 1407-507589, 1427-699391 |
| Wagner Brake | BD180805E, BD180815E |
| Winhere | 6621659, 6621661 |
RAYBESTOS 981503FZN Fits Vehicles
- Mazda CX-3 (2016-2022)
- Mazda 3 Sport (2014-2016)
- Mazda 3 (2014-2018)
RAYBESTOS 981503FZN Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 981503FZN Questions & Answers
No questions yet
Be the first to ask a question about this product!
