(888) 312-8812 Login SignupRAYBESTOS 782057R Raybestos R-Line Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 782057R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2017-2015,2010-2008,2006-2003 Dodge Viper Rear, 2014-2013 SRT Viper Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 782057R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.886 IN |
| Center Hole Diameter | 73.3 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.409 IN |
| Inside Diameter | 239 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.52 IN |
| Mounting Bolt Hole Diameter | 13.2 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.256 IN |
| Nominal Thickness | 31.9 MM |
| Outside Diameter | 13.945 IN |
| Outside Diameter | 354.2 MM |
| Overall Height | 2.047 IN |
| Overall Height | 52 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213218404 |
RAYBESTOS 782057R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH200417 |
| BRAKEBEST | 720911RGS |
| CENTRIC | 120.63056, 120.63056CRY, 121.63056, 126.63056CSL, 126.63056CSR, 126.63056SL, 126.63056SR, 126.63075, 126.63076, 127.63056CL, 127.63056CR, 127.63056L, 127.63056R, 128.63056R, 128.63056L |
| CHRYSLER | 5290393AA |
| Centric Parts | 120.63056, 120.63056CRY, 121.63056, 126.63056CSL, 126.63056CSR, 126.63056SL, 126.63056SR, 126.63075, 126.63076, 127.63056CL, 127.63056CR, 127.63056L, 127.63056R, 128.63056L, 128.63056R |
| Qualis | 43162 |
| Wagner Brake | BD126313, BD180312, BD180313 |
RAYBESTOS 782057R Fits Vehicles
- SRT Viper (2013-2014)
- Dodge Viper (2003-2006, 2008-2010, 2015-2017)
