(888) 312-8812 Login SignupDELPHI TC1108 Control Arm and Ball Joint Assembly
Tap to view 2 more
$20949
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 5
DELPHI TC1108 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1108 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Grooved |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.346 IN |
| Control Arm Maximum Width | 85.00 MM |
| Control Arm Color | Black |
| Ball Joint Stud Length | 2.827 IN |
| Ball Joint Stud Length | 71.80 MM |
| Control Arm Maximum Length | 16.929 IN |
| Control Arm Maximum Length | 430.00 MM |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 14.40 MM |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Mounting Hole Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604272879 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1108 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 102-6556 |
| CORTECO | 49397168 |
| DORMAN | 520-583, CB28023, CB28023PR |
| MAS Industries | CB28023 |
| MEYLE | 0160500012 |
| MOOG | RK622292 |
| MOOG Chassis Products | CK622292, K622292, RK622292 |
| Mercedes-Benz | 124 330 3807 |
| N/A | 2013303807, A124 330 3807, A2013303807 |
| TRW | JTC222 |
| VAICO | V307144 |
DELPHI TC1108 Fits Vehicles
- Mercedes-Benz 190E (1984-1986)
- Mercedes-Benz 190D (1984-1989)
DELPHI TC1108 Customer Reviews
No reviews yet
Be the first to review this product!
DELPHI TC1108 Questions & Answers
No questions yet
Be the first to ask a question about this product!
