(888) 312-8812 Login SignupDELPHI TC1715 Ball Joint
Tap to view 2 more
$2349
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 5
DELPHI TC1715 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC1715 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Maximum Outside Diameter | 1.693 IN |
| Maximum Outside Diameter | 43.00 MM |
| Color | Gray |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 102 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 3.780 IN |
| Nuts Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.906 IN |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| Stud Tapered End 2 Diameter | 0.583 IN |
| Stud Tapered End 2 Diameter | 14.8 MM |
| Stud Tapered End 1 Diameter | 0.732 IN |
| Stud Tapered End 1 Diameter | 18.6 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 93.00 MM |
| Length | 3.660 IN |
| Stud Thread Diameter | 0.55 IN |
| Height | 96.01 MM |
| Stud Thread Length | 23.01 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604275443 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1715 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-3841, 101-4173 |
| DORMAN | B9371, B9371PR |
| Datsun/Nissan | 40160-01E00, 40160-51E00, 40160-85E00, 4016001E25, 4016005E00 |
| MAS Industries | B9371 |
| MOOG Chassis Products | K9371 |
| Mevotech | MK9371 |
| N/A | GK9371, B9371PR |
| TRW | JBJ180 |
DELPHI TC1715 Fits Vehicles
- Nissan Multi (1986-1988)
- Nissan Axxess (1990-1995)
- Nissan Stanza (1986-1992)
- Nissan Maxima (1985-1994)
