(888) 312-8812 Login SignupDELPHI AF10421 Mass Air Flow Sensor
$27449
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Mar 17
DELPHI AF10421 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10421 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Color | Black and Silver |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 5 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 52 MM |
| Sensor Casing Width | 54 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 40.30 MM |
| Mounting Hole Diameter | 0.2 IN |
| Seal Outside Diameter | 46 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 2.0 IN |
| Sensor Casing Width | 2.1 IN |
| Bolt Hole Center To Bolt Hole Center | 1.50 IN |
| Mounting Hole Diameter | 5.5 MM |
| Seal Outside Diameter | 1.8 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604282588 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10421 Cross References
| Brand | Part Number |
|---|---|
| BMW | 13 62 7 566 990 |
| BWD | MA1244 |
| Bosch | 0280218270 |
| CARDONE Reman | 74-51002 |
| Carquest | MQ7414 |
| GLOBAL PARTS DISTRIBUTORS | 1813221 |
| N/A | MQ6280, MF21242 |
| NAPA Reman Computers | XTP451002 |
| SPECTRA PREMIUM | MA478 |
| STANDARD IGNITION | MAS0412 |
| Standard Motor Products | MAS0412 |
| URO | 13627566990 |
| WALKER PRODUCTS | 245-1304 |
DELPHI AF10421 Fits Vehicles
- BMW 650i xDrive Gran Coupe (2013)
- BMW 650i Gran Coupe (2013)
- BMW 650i xDrive (2012-2013)
- BMW 550i GT xDrive (2010-2013)
- BMW 550i xDrive (2011-2013)
- BMW Alpina B7L xDrive (2011-2015)
- BMW Alpina B7 xDrive (2011-2015)
- BMW Alpina B7L (2011-2015)
- BMW X5 (2011-2013)
- BMW Alpina B7 (2011-2015)
- BMW 750i xDrive (2010-2012)
- BMW 750Li xDrive (2010-2012)
- BMW 550i GT (2010-2013)
- BMW X6 (2008-2014)
- BMW 650i (2006-2010, 2012-2013)
- BMW 550i (2006-2013)
- BMW 750Li (2006-2012)
- BMW 750i (2006-2012)
